BendPak PCL-18B-8 18,000 lb. per Portable Column Lift (Set of 8) - New Gray

BendPak PCL-18B-8 18,000 lb. Portable Column Lift (Set of 8) - New Gray

The BendPak PCL-18B-8 mobile column lift system is the perfect fit for heavy-duty fleet maintenance facilities that demand unmatched power, versatility, and mobility. This professional-grade 8-column configuration delivers an impressive 144,000 lb. total system capacity, with each individual column rated for 18,000 lbs. Whether you're working on light trucks, two-axle service vehicles, or massive three-axle heavy-duty equipment, the PCL-18B Series gives you the flexibility to lift virtually any vehicle with confidence. ALI/ALCTV certified, surface-mounted, and completely portable, this system requires no excavation or costly site preparation—just position the columns and start lifting.

Model Options: Available in sets of 2 (PCL-18B-2, 36,000 lbs.), 4 (PCL-18B-4, 72,000 lbs.), 6 (PCL-18B-6, 108,000 lbs.), or 8 columns (PCL-18B-8, 144,000 lbs.) to meet the unique needs of your service bays and vehicle fleet. Portable and surface-mounted design means no excavation or expensive site preparation.

To view the lift inspection guide, click here.

The Perfect Fit for Your Heavy-Duty Maintenance Facility

The PCL-18B Series proudly adds to BendPak's distinctive history of building the best lifts money can buy with evolutionary steps in ergonomics, power, safety, durability, and performance. These portable column lifts are designed exclusively for heavy-duty fleet service and are precisely suited for the toughest applications. Portable and surface-mounted means no excavation or expensive site preparation—just roll into position and get to work.

BendPak mobile column lifts provide the flexibility and convenience to lift vehicles ranging from light trucks to the largest two- and three-axle vehicles up to 144,000 pounds (with 8-column sets) with varied axle or wheelbase lengths. They deliver more of what you need on every job: limitless lift cycles to keep you working longer, more flexibility to work on a wide variety of vehicles, easier and safer operation, and more features and productivity-enhancing tools matched to your needs.

The PCL-18B Series defines professional-level performance and quality—from the super-efficient 208-240V three-phase power system (optional voltages available upon request) to a simplistic yet durable design that helps reduce scheduled service requirements and operating costs. Never before has a series of portable column lifts delivered so much power and versatility for both indoor and outdoor* applications.

*Outdoor use only if covered and dry

Maximum Productivity and Effortless Operation

The PCL-18B portable column lift systems feature a user-friendly and revolutionary design that reduces operator fatigue, meaning a mobile lift that's easier to use and set up—and much faster than competitive units. They allow your technicians to get vehicles in the air and back on the road faster and easier than ever before.

Because the PCL-18B uses an energy-efficient on-demand electric-hydraulic power system, it requires no constant recharging, so it's ready around the clock—providing measurably longer work cycles than any other mobile column lift in its class. Lifting speed: approximately 85 seconds for a full rise cycle.

Ergonomic Steering Control for Effortless Mobility

Durable, versatile, and simple to use, the PCL-18B features an ergonomic pallet-jack style steering control with a built-in hydraulic jack that elevates the lift assembly in seconds and dramatically reduces operator fatigue and downtime. A 180-degree handle with familiar pallet-jack controls provides exceptional maneuverability in compact areas and a tight 40-inch turning circle.

Tandem 8-inch diameter polyurethane-covered steel wheels with sealed roller bearings easily roll over dirt and debris. With an effortless three strokes of the handle, the lift column is raised off the floor for instant portability. Once the column is positioned, the convenient spring-loaded handle returns efficiently to the upright position automatically. In the event the lift is raised with the steering wheels in the elevated position, an overload bypass valve protects the steering control unit.

Horseshoe Wiring for Unobstructed Access

For a standard four-column set, the PCL-18B-4 uses just three 30-foot control cables (as opposed to four like other brands), so the front or back of the lift is always accessible and free of interconnecting cable obstruction. Save valuable time by driving vehicles in and out of the work area without disconnecting and reconnecting cables. This innovative "horseshoe" configuration keeps your workspace clear and speeds up vehicle throughput.

Powerful and Reliable Hydraulic Design

Low-pressure HVLP direct-drive cylinders eliminate the need for lifting chains or expensive-to-maintain screw-drive systems. Inverted hydraulic cylinders mean the chrome piston rods are protected from debris and damage at all times, which extends the service life and reduces maintenance costs substantially.

Independent self-contained electric-hydraulic power units (one per column) are fast, smooth, and reliable and include a motor, gear pump, reservoir, internal valving, a load-hold check valve, and pressure relief circuit in a reliable yet easily serviceable assembly. An enclosed electric-hydraulic power system ensures quieter operation and is better suited for sound-sensitive areas.

Each cylinder features an integrated safety valve to prevent accidental uncontrolled lowering in the event of oil pressure loss, and manual safety override valves on each column permit the lift to be lowered in the event of a power outage without the need for manual hand cranks.

Industry-Best Mobility and Stability

Six-inch diameter Cush-Ride™ front wheels feature an adjustable active leaf spring design that provides variable up-front ground clearance for smooth traveling over uneven floors, deteriorating asphalt, expansion seams, and thresholds. You set the front wheel ride-height to whatever setting best suits your conditions.

Turn the adjusting screw to the max setting and the front legs rise nearly three inches off the ground to facilitate roll-on roll-off loading of trailers and rollback trucks or to make easy passage of drainage gutters or floor irregularities. During operation, the front wheels automatically compress and settle down, providing firm, stable support of the lift column.

Low-mounted power units and cylinders mean a lower center of gravity, making the columns easier to move and less likely to topple compared to screw-drive systems with heavy overhead motors and drive systems. Pallet-jack style steering wheels enable the columns to be lowered firmly on the floor vs. constantly loaded spring-type steering wheels that can cause columns to roll when unladen with the weight of a vehicle.

Durable forklift pockets provide simplistic handling when moving the lift columns from one facility to another. Each column weighs approximately 1,450 lbs.

Intelligent Push-Button Controls and Smart Electronics

Operator convenience is a key parameter in the design of the PCL-18B. The PLC-based control system is operated by means of intuitive push-button controls for continuous synchronization of all columns. All operator instructions, symbols, and warnings are printed in clear text and are easy to understand.

The PCL-18B Series allows you to operate, view, and change operation parameters directly from each individual full-control panel. Control systems feature 24-volt safety circuitry, and electronics are multi-fuse protected. Each column is equipped with an emergency shut-off switch that quickly shuts off power to the lift in the event an unsafe condition is detected by the operator. A separate key lock enclosure on each column provides added security.

Smart electronics feature self-diagnostics and self-calibration functions. If a system error is detected or if the life of a consumable part is nearly expired, fault code indicators are instantly lighted. This allows the user and service coordinator to take appropriate action. If critical faults are detected, all operation functions will be disabled until the affected condition is corrected.

Sealed and enclosed linear potentiometers feature precision potentiometric output and high-frequency response for precise synchronization and communication of all columns throughout all operation cycles for precise, level lifting.

Off-the-Shelf Componentry for Easy Serviceability

A Direct Logic™ PLC (Programmable Logic Control) and other off-the-shelf components from top-tier hardware manufacturers control operation functions and column synchronization. Other lift systems may use dedicated proprietary printed circuit boards specific to that brand, which can be very expensive should replacement ever be needed—if and when available. All control system hardware conforms to CE, CSA, ANSI, ASME, OSHA, and UL regulations.

Advanced Safety and Locking Systems

Multiple, automatic, independent safety locks spaced every 4 inches ensure safe operation. Variable height limit settings can be programmed for shops with low ceilings or when specific vehicle service requirements necessitate specific rise heights. Maximum lifting height is 71.5 inches, with overall height raised at 101 inches and lowered at 146.5 inches.

Each column is equipped with a warning light and audible alarm for critical warning alerts. Ultimate level error protection makes sure that if for any reason the lift operation exceeds a specified out-of-level tolerance threshold, all lift columns will stop and display an out-of-level tolerance error. To clear the error, an offending lift would be put in SINGLE mode and raised or lowered accordingly to reduce the difference in lift heights.

Extended Forks and Versatile Wheel Adapters

Extended forks accommodate wide tires and deep wheel configurations. Multi-width wheel forks with locking pins accommodate the widest range of wheels, eliminating the need for specialty wheel adapters. Minimum lifting fork width: 9.5 inches; maximum lifting fork width: 35 inches; lifting fork length: 11.5 inches. Heavy-duty steel carriage rollers feature turned, ground, and polished axle pins for smooth, reliable operation.

Standard Operation Functions

TEAM, PAIR, or SINGLE COLUMN OPERATION: Selects which lift columns will operate as a group, tandem, or individually. Single mode results in commands from specific lift columns; team and pair modes result in commands from any column designated in their respective group.

UP CONTROL: Initiates the lift rise sequence. Automatic synchronization via auto-level corrections is made throughout all operations in addition to inadvertent loss of motion detection.

DOWN CONTROL: Initiates the lift lowering sequence. If the lift is parked on the locks, the lift will first automatically rise slightly to clear the locks before descending. If the lift is not parked on the locks, the lift will descend immediately with no initial upward movement. During the lowering sequence, the lift will initially descend at a slowed (turtle) speed, and then automatically initiate to full (rabbit) speed after a short delay. Automatic synchronization via auto-level corrections is made throughout all operations in addition to inadvertent loss of motion detection.

PARK CONTROL: Initiates the lift locking (parking) sequence. Each lift column will slowly settle onto the mechanical stops.

TWO-SPEED OPERATION: Parking and lowering speeds are controlled by you. When trying to settle a bus on tall jack stands, go ahead and opt for the slower "turtle" speed for a safe, controlled descent; when the job's done and it's time to remove the vehicle from the work area, select the faster "rabbit" speed for a rapid controlled descent.

EMERGENCY STOP: Shut-off switches on each column quickly shut off power to the lift in the event an unsafe condition is detected by the operator.

Designed and Assembled in USA

At BendPak, we make every effort to use USA-sourced components and engineering for our products. Product development, assembly, testing, and packaging of all PCL-18B lifts is undertaken at our manufacturing facility in Santa Paula, California. Durable powder-coat finish protects the lift for years of reliable service.

You Never Have to Say, "Now What?" Again

We're more than just a lift company; we're a dedicated and highly focused team of experts whose primary commitment is to provide our customers with the best possible after-the-sale service available. Our award-winning Certified Service™ program is how we keep those customers smiling long after the initial purchase of their garage equipment product. When the unexpected happens, BendPak Certified Service™ is your first and final step towards making it right. Even though our business starts with a quality, cost-effective product, we understand that it is the support and services we provide after the sale that help keep your business running at peak efficiency.

Key Highlights

See the PCL-18B in Action
