The BendPak SP-7XEF is the ultimate flush-mount scissor lift for professional shops and enthusiasts who demand full-rise capability with absolute minimal floor profile. With a 7,000 lb. lifting capacity and a maximum rise of 70.5 inches, this full-rise lift provides exceptional working height and access while remaining virtually invisible when lowered flush with your concrete floor. If your garage has a recessed area designed to accommodate flush-mount lifts, the SP-7XEF delivers the perfect combination of performance, safety, and seamless integration—allowing you to drive over the lift when collapsed and work around it without tripping hazards from cables or components above floor level.
Engineered with dual hydraulic cylinders, pneumatic safety locks, and a robust open-center design, the SP-7XEF provides comprehensive undercarriage access for oil changes, transmission work, exhaust service, and countless other repair tasks. Its flush-mount installation eliminates the cross member entirely, reducing drilling and offering true open-center convenience. With eight precision locking heights plus full rise, operators enjoy maximum flexibility for every service scenario—all controlled from an ergonomic operator station that keeps you safe and in control at all times.
The SP-7XEF is the flush-mount version of BendPak's renowned full-rise scissor lift. If your garage has a recessed area of concrete designed to hold flush-mount lifts, you'll be pleased by how "invisible" this lift is in your workspace. When collapsed, you're free to drive over it and work around it without tripping on wires or cables. We're proud that the collapsed SP-7XEF is extremely low-profile, but if you want to take low to virtually zero, the flush-mount version of this model is the perfect car lift solution for your garage.
How Should I Cut Concrete for a Flush-Mount Full-Rise Lift? To view or download detailed concrete cutting specifications, click here.
With 68 inches of lifting height and an open center, many mechanics have comfortable standing room to perform oil changes, transmission drops, and an infinite number of other undercarriage services. The unobstructed center design means you can walk freely beneath the vehicle, access all critical areas without stooping or crawling, and complete jobs faster with far greater comfort and efficiency.
The SP-7XEF is installed and mounted flush into your flooring without a cross member. This makes for a true open-center design that provides access to all critical undercarriage areas without requiring operators to stoop or crawl across the floor. Plus, there's less drilling into concrete, because space will only need to be made for the scissor structures—no longer for a cross member.
Reinforced steel at the base and along the top of the runways help provide a stable lift that completely eliminates the need for that cross member or additional structural support. This design innovation not only simplifies installation but also maximizes your working clearance and maneuverability under the vehicle.
The heavy-duty boxed-steel formed base frame increases stability and reduces stress on the overall structure. The elongated base provides a solid foundation for a smoother, perfectly level rise—ensuring every lift cycle is balanced, controlled, and safe. This robust foundation is critical for flush-mount applications, where the lift must withstand the forces of being recessed and driven over repeatedly.
An electric hydraulic power system is housed in a rugged console box positioned off to the side of the lift, safely away from the lifting and lowering action of the frames moving in and out of your flooring. The ergonomic controls are easy to reach and allow you to keep an eye on your surroundings while lifting and lowering heavy vehicles. The 208-240 VAC / 50-60 Hz / 1Ph motor delivers reliable power and quick lifting times—raising the full 7,000 lbs. capacity in approximately 45 seconds.
In order to push the frames out from a flush-mount position quickly and powerfully, the SP-7XEF is fitted with two hydraulic cylinders with flow restrictors to ensure an even lift. This dual-cylinder hydraulic design provides extra power and controlled flow that is sophisticated enough to prevent the risk of tipping—even if one cylinder loses pressure (due to an unlikely rupture or pinch, for instance).
No emergency will result in the up-ending of your vehicle—the car lift would simply descend to the ground evenly on both frames, maintaining balance and safety at all times. This redundancy is a hallmark of BendPak engineering and a critical safety feature for any professional or home garage.
A single convenient operator stand allows you to release the pneumatic safety locks from a safe distance without ever worrying about manually lifting release arms or latches. The locks disengage when the lift lowers and automatically engage at multiple locking positions, providing operators with more service options and greater flexibility.
The SP-7XEF offers eight distinct locking heights plus full rise, ranging from 24.75 inches at the first lock position all the way up to 70 inches at the eighth lock, with full rise at 70.5 inches. The locks engage or disengage at each position seamlessly with the movement of the scissor lift frames, ensuring your vehicle is always secure at the height you need.
Zerk grease fittings are self-lubricating and long-lasting, ensuring a smooth rise and descent of the lift platforms at all times. The hardened pivot pins are engineered for durability and reduced wear, providing thousands of reliable lift cycles with minimal maintenance. Regular lubrication through the Zerk fittings keeps all moving parts operating smoothly and extends the lifespan of your investment.
Hard rubber blocks are set right atop the rubber padding on the lift platforms, safely and securely engaging vehicle pinch rails and OEM frame lift points. These cushioned rubber contact blocks protect your vehicle's frame and undercarriage while providing a secure, non-slip grip during lifting and lowering. The dual-layer design absorbs shock and vibration, ensuring gentle, damage-free contact with every vehicle type.
An easy-to-read owner's manual offers complete installation instructions and maintenance tips, as well as safety/caution decals that come standard with every lift purchase. BendPak provides comprehensive documentation to ensure your flush-mount installation is performed correctly and safely, and to help you maintain peak performance for years to come.
Looking for full specifications and features?
Check out the Product Specifications and Product Features tabs
above for complete specs, dimensions, and detailed feature breakdowns.
LOW-RISE/MID-RISE LIFTS WARRANTY
Duration: From the date of purchase by the original Purchaser or 12-24 months from the date of shipment by BendPak or whichever comes first.
Limited Warranty
1. Who gives this warranty (Warrantor): BendPak Inc., 1645 Lemonwood Dr., Santa Paula, CA 93060
2. Who receives this warranty (Purchaser): The original Purchaser (other than for purpose of resale)
3. What products are covered by this warranty: Any BendPak Full-Rise Scissor Lift**
4. What is covered under this warranty: manufacturer defects due to material and/or workmanship with the exceptions noted below.
5. What is not covered under this warranty:
a. Any failure that results from Purchaser’s abuse, neglect or failure to operate, maintain or service product in accordance with instructions provided in the owner’s manual(s) supplied
b. Any damage caused by overloading lift beyond rated capacity
c. Items or service normally required to maintain the product, i.e. lubricants, oil, etc.
d. Items considered general wear parts such as rubber pads, pad adapters, etc. unless wear or failure is a direct result of manufacturer defect due to material and/or workmanship
e. Any component damaged in shipment or any failure caused by installing or operating lift under conditions not in accordance with installation and operation guidelines or damaged by contact with tools or surroundings
f. Motor or pump failure caused by rain, excessive humidity, corrosive environments or other contaminants
g. Rusted components due to improper maintenance or corrosive environments
h. Cosmetic defects that do not interfere with product functionality
i. Damage due to incorrect voltage or improper wiring
j. Any incidental, indirect, or consequential loss, damage, or expense that may result from any defect, failure, or malfunction of BendPak Inc. product
k. All electrical components are guaranteed for one year against defects in workmanship and/or materials when the lift is installed and used according to specifications.
6. Responsibilities of Warrantor under this warranty: Repair or replace, at Warrantor’s option, component which is defective, has malfunctioned and/or failed to conform within duration of the warranty period. BendPak Inc. will pay reasonable labor costs for the first 12 months only
7. Responsibilities of Purchaser under this warranty:
a. Provide dated proof of purchase and maintenance records
b. In some cases, components may be required to be shipped to the nearest BendPak Authorized Service Center. Freight costs, after 12-months, must be borne by the Purchaser.
c. Use reasonable care in the operation and maintenance of the products as described in the owner’s manual(s).
8. When Warrantor will perform repair or replacement under this warranty: Repair or replacement will be scheduled and serviced according to the normal work flow at the servicing location, and depending on the availability of replacement parts.
*Free-shipping applies to direct shipping points within the 48 continental United States. Rural area shipping surcharge may apply for remote
addresses.
**For all BendPak brand Low-Rise and Mid-Rise Surface Mounted Vehicle Service Lifts (excluding specialty lifts, high rise, commercial
parking, material handling, or models for particular purpose) manufactured on or following 7/27/2012.
Limitation of Liability
BendPak/Ranger shall have no obligation pursuant to this Warranty with respect to products which in our sole judgment have been altered
damaged, misused, abused, badly worn, lost or improperly maintained. This Warranty is null and void if the customer or any other person other
than an authorized representative of BendPak/Ranger has made any attempt to service or modify the tool prior to its return to BendPak/Ranger
under this Warranty. In no event will either party be liable for any damage caused by the other party's failure to fulfill its responsibilities under
these terms and conditions. In no event will either party be liable for any lost profits, lost savings, incidental damage, or other economic
consequential damages. All expressed and implied warranties, including the implied warranties of merchantability and fitness for a particular
purpose, are limited in duration to the coverage period. No warranties, expressed or implied, will apply after this period. BendPak may modify
these terms and conditions at any time by either providing the customer with written notice or posting such revised terms on
www.bendpak.com. Such revised terms shall be effective thirty days from the date of such written notice or posting.
