The Corghi A9824TI is a passenger and light truck tire changer that combines superior Italian engineering with a sleek design and powerful performance features. Available with your choice of air or electric motor, this machine delivers tire service speeds up to 50% faster than competing models in its price range. Corghi was awarded ISO 9001 Quality Certification, the industry's most coveted quality award, and this machine is run-flat certified by all major tire manufacturers.
With a heavy-duty stainless steel turntable delivering 737 ft-lb of rotation torque, the A9824TI handles tires up to 47" diameter and rims from 10" to 24" externally (expandable to 8" to 28" with optional adapters). The machine's unique mount/demount head is engineered to work without touching the rim during operation, protecting expensive wheels from damage. An innovative bead-pressing lever and powerful action bead-breaker blade that follows the bead to the inside rim contour ensure fast, safe tire service every time.
The A9824TI is built for high-volume shops that need speed, safety, and reliability. The turntable rotates in either direction at 11 rpm, giving technicians full control during tire mounting and dismounting. The upper arm assembly swings out of the way for easy wheel loading and unloading, while the bead-pressing lever assists with stubborn beads on low-profile and run-flat tires.
With a footprint of just 78" H x 48" W x 42" D and weighing 503 lbs, this machine is compact enough for shops with limited floor space, yet robust enough to handle demanding daily use. The 110V / 1PH / 50 Hz electrical requirement and 130 psi air supply make it easy to integrate into any shop environment.
Looking for full specifications and features?
Check out the Product Specifications and Product Features tabs above for complete specs, dimensions, and detailed feature breakdowns.
Installation and Training Included:
Installation and training will be provided on the purchase of all new machines except the @120 changer, @601 balancer, TS24 Tire Dunker, IC90 Inflation Station and all Service Pro models.
Take advantage of the Corghi Customer Loyalty Program for exclusive benefits and support. Click the link to view or download the customer loyalty form.
The Corghi A9824TI ships at 608 lbs and comes ready to install with the included manual and professional support. Experience the difference that Italian engineering, thoughtful design, and industry-leading performance bring to your tire service operation.
Limited Warranty
General Terms
Corghi USA expressly warrants its products will be free from defects in material and/or workmanship for the time period specified. Corghi USA must be informed in writing within 7 days after discovery of a defect. Corghi USA reserves the right to repair or replace a product at our discretion. Consumable products and accessories such as but not limited to; plastic protection parts, bead breaker pads, inflation hoses, and rollers, are not covered under this warranty.
This warranty does not cover any damage resulting from abuse or failure to perform any necessary maintenance (i.e. damage due to or resulting from, faulty installation, neglect, misuse, improper electrical connections or electrical surges, problems resulting from excessive water, contaminated air system, or pollutant of any nature, fire or freight damage).
A2030, A2024TI, 2024LL, A9824, A9824LL, A9830, A9222, Service Pro 124, Service Pro 324, BC200S
NOTE: Rubber Pads, air lines, gauges, mount/demount heads, and swabs - 90 day warranty
Disclaimer & Limitation on Liability
Corghi USA agreement to repair a tire changer or balancer is expressly in lieu of all other warranties, express, implies or statutory, including any warranties for merchantability and fitness for a particular purpose. Corghi USA maximum liability shall be limited to the cost of the machine. In no event shall Corghi USA be responsible for owner’s lost profits, goodwill or other incidental or consequential damages. Corghi USA is not responsible for equipment or accessories damages in shipment. Freight claims are to be made directly with the carrier. We will be more than happy to assist you with any questions regarding filing claims.
To View or Download Corghi Full Warranty Information Click Here
