The iDeal LR-10K-TLPAD is a 10,000 lb. capacity commercial low-rise pad lift engineered for high-performance vehicle service. Designed specifically for express tire and wheel service, this commercial-grade frame contact lift handles a wide range of vehicles including cars, SUVs, vans, and light trucks. Whether you're running a high-volume tire shop, quick lube center, or full-service auto repair facility, this lift delivers the durability, speed, and versatility needed to maximize productivity and profitability.
Featuring a robust surface mount installation configuration, the LR-10K-TLPAD eliminates the need for in-ground installation, saving time and cost during setup. The integrated outer frame with diamond plate ramps provides drive-on and drive-off clearance for wide-body vehicles, while the dual hydraulic lift cylinders ensure smooth, balanced lifting across the entire platform. Advanced safety features include three locking height positions with dual latch release handles conveniently located on each side of the lift, giving technicians flexibility and peace of mind during service operations.
Unmatched Versatility & Shop Layout Flexibility
The versatility of the pad lift design allows vehicles to be driven onto the lift in either direction, making bay positioning and workflow optimization effortless. You can position the hose and power unit to either side of the pad lift, ensuring the best fit for your shop or garage layout. This bidirectional drive-on capability also speeds up vehicle throughput during busy service hours.
The lift accommodates a wide variety of vehicle types, including uni-body vehicles, thanks to the included HD multi-position height adapters and 1.5" rubber pads (4ea). The large 51-1/4" x 24" platform pads provide generous contact area, while the 15" platform forward movement allows precise positioning under the vehicle's frame. The overall 70-3/4" platform outer width accommodates wide-stance vehicles with ease.
Powerful, Reliable Lifting System
Easy lift operation is provided by a high-quality DURO electric/hydraulic power unit mounted on a convenient power unit pedestal stand. The standard 115V / 1 Phase / 20 Amp power configuration offers a 60-second lift speed, perfect for most shop environments. For operations demanding faster cycle times, an optional 220V DURO power unit is available, reducing lift speed to just 36 seconds—approximately 40% faster than the standard unit. This upgrade can significantly boost throughput during peak service hours.
The lift's dual hydraulic cylinders deliver smooth, even lifting and balanced load distribution across the platform. Maximum rise height reaches 22-1/2", with a minimum lift height of just 4-1/4", offering excellent clearance for low-profile vehicles. When paired with the tall adapter option, the lift can reach a maximum height of 30-3/4", providing additional undercarriage access for larger vehicles or more extensive service work.
Safety, Durability & Long-Term Performance
Safety and longevity are paramount in the LR-10K-TLPAD's design. The lift includes durable rubber platform contact pads that protect vehicle frames and reduce slippage. Diamond plate ramps provide sure footing for vehicles during drive-on and drive-off, while the integrated outer frame adds structural rigidity and stability.
Latch release handles are strategically positioned on each side of the lift for easy, ambidextrous operation. The lift locks at three height positions (13.5", 17.25", and 21.5"), giving technicians the flexibility to work at the most comfortable and efficient height for the job. Protective metal hose covers (55"L, 2ea) shield hydraulic lines from shop traffic and accidental damage, extending the lift's operational life.
A durable powder coat finish protects all metal surfaces from corrosion, chemicals, and everyday shop wear, ensuring the lift maintains its professional appearance and structural integrity for years of heavy use. With an overall footprint of 91" L x 88-5/8" W and a shipping weight of 1,262 lbs., this is a substantial, shop-grade piece of equipment built to withstand the demands of commercial automotive service.
Key Highlights
10,000 lbs. capacity – handles cars, SUVs, vans, and light trucks with confidence
Surface mount installation – no in-ground work required, faster setup and lower installation cost
Integrated outer frame with diamond plate ramps – allows drive-on/drive-off clearance for wide vehicles
Three locking height positions (13.5", 17.25", 21.5") with dual latch release handles on each side
Optional 220V power unit – reduces lift speed to 36 seconds for 40% faster operation
Looking for full specifications and features?
Check out the Product Specifications and Product Features tabs
above for complete specs, dimensions, and detailed feature breakdowns.
Included Standard Accessories
Every iDeal LR-10K-TLPAD comes complete with essential accessories to get your shop up and running:
Power unit pedestal stand – keeps the power unit secure and accessible
Metal hose covers (2ea, 55"L) – protect hydraulic lines from damage
HD multi-position height adapters (4ea) – lift uni-body and frame vehicles safely
1.5" rubber pads (4ea) – provide additional lift point cushioning and grip
Note: Corded drill not included. 115V/20A electrical service required (220V optional).
Upgrade to 220V for Faster Service
Optional 220V DURO Power Unit Available
Provides 40% faster speed of rise at just 36 seconds
Electrical plug not provided – requires direct electrical service to breaker
Ideal for high-volume shops where every second counts
All specifications and features are subject to change without notice. Please refer to the Product Specifications and Product Features tabs for the most current and complete information.
Structural Warranty:
The following parts and structural components carry a five year warranty:
Columns
Top Rails
Beams
Uprights
Arms
Swivel
Pins
Legs
Carriages
Tracks
Cross Rails
Overhead Beams
Limited One-Year Warranty:
Tuxedo Distributors, LLC offers a limited one-year warranty to the original purchaser of iDeal Lifts and Wheel Service in the United States and Canada. Tuxedo Distributors, LLC will replace, without charge, any part found defective in materials or workmanship under normal use, for a period of one year after purchase. The purchaser is responsible for all shipping charges. This warranty does not apply to equipment that has been improperly installed or altered or that has not been operated or maintained according to specifications.
Other Limitations:
This warranty does not cover:
Parts needed for normal maintenance
Wear parts, including but not limited to cables, rub blocks, chains, rubber pads and pulleys
Replacement of lift and tire changer cylinders after the first 30 days. A seal kit and installation instructions will be sent for repairs thereafter.
On-site labor
Upon delivery of goods, the Customer has sole responsibility to notify Tuxedo Distributors, LLC of missing parts or concealed damage within 72 hours of receipt. If no notification of missing parts or of concealed damage is made, all parts will be purchased after 72 hours has passed.
Upon receipt, the customer must visually inspect the equipment for any potential freight damage before signing clear on the shipping receipt. Freight damage is not considered a warranty issue and therefore must be noted for any potential recovery with the shipping company.
The customer is required to notify Tuxedo Distributors, LLC of any missing parts within 72 hours. Timely notification must be received to be covered under warranty.
Tuxedo Distributors, LLC will replace any defective part under warranty at no charge as soon as such parts become available from the manufacturer. No guarantee is given as to the immediate availability of replacement parts.
Tuxedo Distributors, LLC reserves the right to make improvements and/or design changes to its without any obligation to previously sold, assembled or fabricated equipment.
There is no other express warranty on the iDeal lifts and this warranty is exclusive of and in lieu of all other
warranties, expressed or implied, including all warranties of merchantability and fitness for a particular purpose.
To the fullest extent allowed by law, Tuxedo Distributors, LLC shall not be liable for loss of use, cost of cover, lost profits, inconvenience, lost time, commercial loss or other incidental or consequential damages.
This Limited Warranty is granted to the original purchaser only and is not transferable or assignable.
Some states do not allow exclusion or limitation of consequential damages or how long an implied warranty lasts, so the above limitations and exclusions may not apply. This warranty gives you specific legal rights and you may have other rights, which may vary from state to state
