9,000 lbs. of lifting capacity. Unobstructed access to the vehicle's undercarriage. Optional ramps or flush-mount design. Minimal footprint. Optional arm adapters. The BendPak P-9000LT is simply the best low-rise car lift money can buy. Fast-lube shops have relied on BendPak pit lifts for years, and our engineers took the proven design to the next level by significantly increasing weight capacity.
The P-9000LT is suitable for more light trucks and SUVs than ever before. Whether you choose the extended approach ramps or flush-mount option, lifting low-stance vehicles is effortless with this lift. It's engineered for maximum versatility, allowing you to convert fast-lube pits into full-service wheel service work bays without sacrificing valuable floor space or center pit access.
Whether you work in a pit or prefer to keep your low-rise lift on the ground, the BendPak P-9000LT is versatile enough to do both. Converting the flush-mount P-9000LTF into a floor model is as simple as attaching the extended approach ramps. These heavy-duty ramps are extended farther and slope very gradually, ensuring low ground-clearance vehicles never scrape or rub against them during drive-up.
The P-9000LT is made with oil-change facilities first and foremost in mind. The open-center, frame-engaging design permits full access to the wheels for tire and brake service, transforming your oil-change business into a legitimate threat to competing auto shops who used to monopolize your wheel service business. Those profitable tire rotations, brake jobs, and suspension services are now within your reach. Capture all that revenue in-house with a lift designed to deliver full-service capability in a compact, pit-friendly package.
This industry-leading lift features a robust 1.5 HP electric-hydraulic power unit, dual hydraulic cylinders with precision flow-divider, simple electronic push-button controls, and automatic multi-position pneumatic safety locks with air release for safe, remote operation.
Pneumatic Lock Release
Air locks provide a safe, instant release that efficiently permits the lowering of vehicles. A single button push is all it takes to disengage the locks and completely lower the lift in seconds flat. This automatic multi-position safety lock system ensures safe operation at any of the lift's multiple locking heights: 15", 19", 21.5", 23.5", and full rise at 24".
Low-Profile Design
At just 4" high when fully lowered, the P-9000LT is one of the most space-effective pit lift models ever engineered. When flush-mounted, its profile virtually disappears completely, leaving your work area clear and unobstructed. The lift platform itself measures 58.5" long by 24" wide, providing ample support while maintaining a compact footprint.
Rugged Steel Channel Frame
The super-wide base provides this 9,000 lbs. of lifting force with excellent support and stability. No one matches the reinforced steel channel frame design of the P-9000LT. Reinforced parallel lifting arms and a reinforced upper lift platform better support inboard loading for maximum safety and performance. BendPak pioneered this design, and ongoing heavy-duty construction ensures we remain the industry leader.
Dual-Pump Power Unit with Built-In Proportioning Valve
The dual-pump hydraulic system ensures smooth, balanced lifting every time. Integrated proportioning valve guarantees even pressure distribution across both cylinders for perfectly level vehicle positioning. Combined with the 1.5 HP / 208-230 VAC / 60 Hz / 1 Ph motor, this lift achieves full rise in just 55 seconds, making your workflow faster and more productive.
Solid Rubber Lift Blocks & Durable Rubber-Topped Pads
We don't charge extra for the rubber blocks you need to lift vehicles safely. These rugged blocks protect vehicle undercarriages and chassis from damage. They're made to take as much use and abuse as your work requires. The durable rubber-topped pad surface provides excellent grip and quick, secure set-up every time.
Enhanced Adjustable Lifting Arms (Optional)
For even greater vehicle compatibility, optional adjustable lifting arms are available, allowing you to fine-tune lift point positioning to match a wider variety of vehicle configurations and lift points.
Every BendPak lift comes complete with an easy-to-read instruction manual, space to keep service records, a comprehensive guide for safe lifting, and a safety/training instruction placard. BendPak stands behind every lift with thorough documentation and support to ensure safe, efficient operation for years to come.
The P-9000LTF flush-mount pit lift mounts flush against the concrete for a completely recessed drive-over option. If you don't want to see the car lift, or you simply need it out of the way in your busy garage, the ramps are completely detachable. That means if you change your mind, you can easily convert your P-9000LT into a P-9000LTF at any time. The Model P-9000LTF gives you the ultimate in installation flexibility and space efficiency.
Looking for full specifications and features?
Check out the Product Specifications and Product Features tabs above for complete specs, dimensions, and detailed feature breakdowns.
*Not all BendPak lift models meet the standards as prescribed by ANSI/ALI ALCTV (Current Edition) or ANSI/UL 201. Consult www.autolift.org for a complete list.
LOW-RISE/MID-RISE LIFTS WARRANTY
Duration: From the date of purchase by the original Purchaser or 12-24 months from the date of shipment by BendPak or whichever comes first.
Limited Warranty
1. Who gives this warranty (Warrantor): BendPak Inc., 1645 Lemonwood Dr., Santa Paula, CA 93060
2. Who receives this warranty (Purchaser): The original Purchaser (other than for purpose of resale)
3. What products are covered by this warranty: Any BendPak Full-Rise Scissor Lift**
4. What is covered under this warranty: manufacturer defects due to material and/or workmanship with the exceptions noted below.
5. What is not covered under this warranty:
a. Any failure that results from Purchaser’s abuse, neglect or failure to operate, maintain or service product in accordance with instructions provided in the owner’s manual(s) supplied
b. Any damage caused by overloading lift beyond rated capacity
c. Items or service normally required to maintain the product, i.e. lubricants, oil, etc.
d. Items considered general wear parts such as rubber pads, pad adapters, etc. unless wear or failure is a direct result of manufacturer defect due to material and/or workmanship
e. Any component damaged in shipment or any failure caused by installing or operating lift under conditions not in accordance with installation and operation guidelines or damaged by contact with tools or surroundings
f. Motor or pump failure caused by rain, excessive humidity, corrosive environments or other contaminants
g. Rusted components due to improper maintenance or corrosive environments
h. Cosmetic defects that do not interfere with product functionality
i. Damage due to incorrect voltage or improper wiring
j. Any incidental, indirect, or consequential loss, damage, or expense that may result from any defect, failure, or malfunction of BendPak Inc. product
k. All electrical components are guaranteed for one year against defects in workmanship and/or materials when the lift is installed and used according to specifications.
6. Responsibilities of Warrantor under this warranty: Repair or replace, at Warrantor’s option, component which is defective, has malfunctioned and/or failed to conform within duration of the warranty period. BendPak Inc. will pay reasonable labor costs for the first 12 months only
7. Responsibilities of Purchaser under this warranty:
a. Provide dated proof of purchase and maintenance records
b. In some cases, components may be required to be shipped to the nearest BendPak Authorized Service Center. Freight costs, after 12-months, must be borne by the Purchaser.
c. Use reasonable care in the operation and maintenance of the products as described in the owner’s manual(s).
8. When Warrantor will perform repair or replacement under this warranty: Repair or replacement will be scheduled and serviced according to the normal work flow at the servicing location, and depending on the availability of replacement parts.
*Free-shipping applies to direct shipping points within the 48 continental United States. Rural area shipping surcharge may apply for remote
addresses.
**For all BendPak brand Low-Rise and Mid-Rise Surface Mounted Vehicle Service Lifts (excluding specialty lifts, high rise, commercial
parking, material handling, or models for particular purpose) manufactured on or following 7/27/2012.
Limitation of Liability
BendPak/Ranger shall have no obligation pursuant to this Warranty with respect to products which in our sole judgment have been altered
damaged, misused, abused, badly worn, lost or improperly maintained. This Warranty is null and void if the customer or any other person other
than an authorized representative of BendPak/Ranger has made any attempt to service or modify the tool prior to its return to BendPak/Ranger
under this Warranty. In no event will either party be liable for any damage caused by the other party's failure to fulfill its responsibilities under
these terms and conditions. In no event will either party be liable for any lost profits, lost savings, incidental damage, or other economic
consequential damages. All expressed and implied warranties, including the implied warranties of merchantability and fitness for a particular
purpose, are limited in duration to the coverage period. No warranties, expressed or implied, will apply after this period. BendPak may modify
these terms and conditions at any time by either providing the customer with written notice or posting such revised terms on
www.bendpak.com. Such revised terms shall be effective thirty days from the date of such written notice or posting.
