Need help with installation? Our AI assistant has read this installation manual and can help you find the right page and walk you through each step.
The Atlas® 6PL Low Rise Scissor Lift delivers 6,000 lbs of lifting capacity in a compact, low-profile design perfectly suited for tire shops, quick service centers, and busy automotive facilities. With a 4½" minimum height and 26" maximum lift height, the 6PL provides the ideal working range for tire rotations, brake service, suspension work, and routine maintenance tasks that don't require full undercarriage access.
Built with commercial-grade quality, this 110-volt electric-hydraulic scissor lift features an open center design that provides easier access to the underside of vehicles while maintaining stability and safety. The air-operated single point lock release ensures precise control and operator convenience, while the drive-over ramps make vehicle positioning quick and effortless.
Each Atlas 6PL includes a complete set of four non-slip rubber pads and heavy-duty rubber lifting blocks to protect vehicle lifting points and provide secure contact surfaces. With 53" x 18" platforms and a variable 36½" spacing between runways, this lift accommodates a wide range of passenger vehicles and light trucks. All mounting hardware is included for straightforward installation.
Important Installation Note: To view or download the lift inspection guide, click here.
Operating the Atlas 6PL is straightforward and efficient. Simply drive the vehicle over the lift platforms and position the included rubber lifting blocks under the manufacturer-recommended lifting points. Press the button on the power unit to raise the vehicle to your desired working height. When you're ready to lower, depress the dump valve lever on the power unit and the lift descends smoothly to the next lower mechanical lock position.
The lift operates on standard 110V/60Hz/1Ph power (30 amp breaker required) and requires 85-120 psi air supply for the lock release system. The hydraulic system uses 1.5-2 gallons of AW32/AW46 oil, and the entire unit ships at 850 lbs, making installation manageable for most facilities.
Critical Operating Requirement: Due to the horizontal cylinder configuration of the 6PL, it is essential to allow 2-6 inches of space between the lifting surface and the vehicle's lifting points before raising the lift.
Why won't my scissor lift raise its rated capacity? For detailed information about horizontal vs. vertical cylinder performance, click here.
Looking for full specifications and features?
Check out the Product Specifications and Product Features tabs
above for complete specs, dimensions, and detailed feature breakdowns.
The Atlas 6PL Low Rise Scissor Lift excels in quick-service environments where speed and efficiency matter most. It's particularly well-suited for:
The 71" overall width and 53" x 18" platform dimensions provide a stable, wide footprint that accommodates vehicles of various sizes while maintaining a compact shop footprint.
Warranty Information
To View Atlas® 6PL Warranty Click Here
