FS-Curtis NxB06 7.5HP Rotary Screw Air Compressor w/Fixed Speed Base Mounted

Previous Next

FSCurtis

FS-Curtis NxB06 7.5HP Rotary Screw Air Compressor w/Fixed Speed Base Mounted

Name: FS-Curtis NxB06 7.5HP Rotary Screw Air Compressor w/Fixed Speed Base Mounted
Brand: FSCurtis
SKU: NxB06-B
Price: 10754.76 USD
Availability: InStock

0 review Write a Review

$10,754.76

(You save: $1,173.24 )

Product Code: NxB06-B

Hurry up! Current stock:

Options

Delivery Options: *

Delivery Notice: *

Choose a Voltage / PSI: *

Base Unit w/Integrated Dryer:

Quantity:

Product Details
Warranty Information
Product Features
Product Specs

Product Details

```html

FS-Curtis NxB06 7.5HP Rotary Screw Air Compressor w/Fixed Speed Base Mounted

📄 Download Installation Manual

Need help with installation? Our AI assistant has read this installation manual and can help you find the right page and walk you through each step.

The FS-Curtis NxB06 delivers professional-grade compressed air performance in a compact, 7.5HP rotary screw design perfect for automotive shops, light manufacturing, woodworking, and demanding service applications. Engineered with eCool® Technology, the NxB06 provides superior component cooling that extends motor and electrical life up to 50% longer while reducing thermal stress across the entire unit. This Made in the USA compressor combines reliable 100% continuous-duty operation with whisper-quiet 65 dBA sound levels and intelligent iCommand Basic electronic controls—delivering stable air pressure, steady airflow, and exceptional efficiency in a space-saving footprint.

Stable air pressure, steady airflow and quieter, continuous-duty operation are just a few of the advantages you get with FS-Curtis rotary screw compressors. These smart, compact units also offer better air quality with less oil carryover than reciprocating models. Intuitive controls and diagnostics make them easy to use and service, too. It all adds up to an extremely reliable machine that can run 100% continuous duty, delivering more airflow and better efficiency in a space-saving design—making the Nx Series ideal for automotive, light industrial and other applications that require reliable performance in demanding conditions.

Compact in design, robust in power, the Nx's smooth, quiet operation is ideal for a wide variety of applications ranging from auto body shops to light industrial facilities.

Key Advantages

Whisper-Quiet Operation: At just 65 dBA, the NxB06 integrates centrifugal blower and drive motors with extra-thick sound insulation for exceptionally smooth, quiet performance—ideal for noise-sensitive environments.
eCool® Technology: Exclusive compartmentalized airflow design maximizes cooling efficiency, protecting critical components from compressor-generated heat and extending service life up to 50% longer for motors and electrical components and 30–50% longer for bearings, hoses, and seals.
Superior Air Quality: Spin-on air/oil separator delivers 1–3 PPM oil carryover, translating into lower make-up oil costs and higher quality compressed air for your tools and processes.
Flexible Configuration: Available in 230V single-phase or tri-voltage models, with pressure options from 100 PSI to 175 PSI. Optional integrated dryer models provide all-in-one air treatment.
100% Continuous Duty & Energy Efficiency: Exclusive FS-Curtis airends with advanced rotor profiles maximize CFM per horsepower, delivering pulsation-free air and extended service intervals for the lowest cost of ownership.

dBA Shield Noise Reduction

Designed for quiet operation.

Integration of centrifugal blower and drive motors make for extremely smooth and quiet operation
Extra-thick sound insulation reduces noise
Can be installed in applications where a quiet setting is important

eCool® Technology – A Cool Innovation

Compressors generate heat. FS-Curtis' exclusive eCool® technology provides protection from heat and reduces thermal stress.

By combining smart compressor layout with intelligent component selection, eCool® technology maximizes cooling airflow for greater energy efficiency, improved reliability and increases service life up to 50% longer for motors and electrical components and up to 30–50% longer for bearings, hoses and seals.

The ultimate in system protection and reliability.

Protects critical components from compressor-generated heat
Extends component life and reduces downtime
Compartmentalized air flow design and standard aftercooler

Quality Components

Built to the highest levels of dependability and reliability.

Standard TEFC (IP55) motor protects compressor from surrounding dirty air, increasing the efficiency and prolonging the life of the motor.
Spin-on air/oil separator allows for quick maintenance and results in one-to-three PPM oil carryover. This translates into lower make-up oil costs and higher quality compressed air.
Premium Efficiency TEFC motor, NEMA-1 electric panel, full voltage motor starter, and 115/18V control voltage transformer
Encapsulated airend, spin-on oil filter, air cooled oil cooler, multi-function oil valve, and vibration isolators
Factory filled with synthetic lubricant for extended service intervals and superior lubrication

Superior Package Design

Designed for low cost of ownership and easy service.

Space-saving design – 30" L × 24" W × 38" H (base unit) or 42" L × 24" W × 38" H (with integrated dryer)
Pulsation-free air
100% continuous duty
Extended service intervals
More CFM per horsepower
Improved air quality
Energy efficiency at full load delivers more air for the money integrated into a smaller footprint
Exclusive FS-Curtis airends utilize the latest rotor profile to maximize efficiency
Powder-coat painted enclosure and laminated oil-proof sound insulation
Built-in heavy duty air intake filter

Available Configurations

Standard Available w/iCommand Basic – Voltage / Pressure PSI

230V 1 Phase:

1/60/230V 100 PSI – FNB06AXX2HXXX
1/60/230V 125 PSI – FNB06AXX2JXXX
1/60/230V 150 PSI – FNB06AXX2KXXX
1/60/230V 175 PSI – FNB06AXX2LXXX

Tri-voltage:

Tri-voltage 100 PSI – FNB06AXXTHXXX
Tri-voltage 125 PSI – FNB06AXXTJXXX
Tri-voltage 150 PSI – FNB06AXXTKXXX
Tri-voltage 175 PSI – FNB06AXXTLXXX

Base Mounted w/iCommand Basic & Integrated Dryer – Voltage / Pressure PSI

230V 1 Phase:

1/60/230V 100 PSI – FNB06AXD2HXXX
1/60/230V 125 PSI – FNB06AXD2JXXX
1/60/230V 150 PSI – FNB06AXD2KXXX
1/60/230V 175 PSI – FNB06AXD2LXXX

Tri-voltage:

Tri-voltage 100 PSI – FNB06AXDTHXXX
Tri-voltage 125 PSI – FNB06AXDTJXXX
Tri-voltage 150 PSI – FNB06AXDTKXXX
Tri-voltage 175 PSI – FNB06AXDTLXXX

Optional Accessory: iCommand Touch Controller

With the optional iCommand-Touch, a full-color screen displays graphs which capture and track factual, real-time air usage by the hour, day, week and month. Historical data can be retrieved at any time at the touch of the screen.

Data trending keeps your finger on the pulse of your entire compressed air system.

Continuously tracks pressure, temperature, air quantity and usage to easily diagnose and optimize your plant's air system.

Simple Touch Screen Control
Intuitive Navigation
Capture Realtime and Historical Data Trending

Looking for full specifications and features?
Check out the Product Specifications and Product Features tabs above for complete specs, dimensions, and detailed feature breakdowns.

```

Warranty Information

Extended Warranty Policy
FS-Curtis is dedicated to providing industry leading warranty programs. These warranties provide additional peace-of-mind to products which already enjoy best-in-class quality. All FS-Curtis NX products are backed by a Standard Manufacturers Warranty of 12 months. The NxGEN warranty program detailed below can provide added protection. To participate in the NxGEN Warranty Program the requirements listed below must be performed and documented throughout the full warranty period..

Requirements

All Rotary Screw air compressors are required to have the “start up” procedure completed by and authorized FS-Curtis distributor and returned to FSCurtis within 30 days of the compressor package start-up. Please email the completed check list to warranty@fscurtis.com. Form# WRSC-002.
The NxGEN Extended Warranty Program requires the Nx product to be registered at http://info.us.fscurtis.com/support/warranty/register.htm.
A minimum of one Annual Service Kit must be purchased on an annual basis, which is defined as 12 months. The Annual Service Kit should be purchased within 60 days prior to the anniversary date of the compressor package start-up date. Individual genuine parts and lubricants as specified in the service manual can be purchased. Nx products must be maintained in accordance with the maintenance schedules provided in the service manuals for the appropriate service interval using only FS-Curtis genuine parts and lubricants for the entire warranty period. Proof of purchase (i.e. product invoice) will be required in the event a warranty claim is filed and these purchases must correlate with the recommended maintenance guidelines in the service manual for the corresponding operating hours of equipment.
Participation in the FS-Curtis oil analysis sampling program is required. An oil sample must be sent to our testing facility at minimum two times a year which is defined as 12 months or once every 6 months. Any recommendations detailed in the analysis report must be followed as outlined in the report. Oil sample kits are available upon request.
The use of FSC-8000 lubricant is required. The lubricant must be changed as per the service manual intervals, oil analysis recommendations or at minimum every 12 months. Oil filter and separator must be replaced at the time of the lubricant change.

ALL OF THE ABOVE REQUIREMENTS MUST BE PERFORMED AND DOCUMENTED TO ENSURE THE NXGEN WARRANTY PROGRAM IS IN EFFECT FOR THE FULL WARRANTY PERIOD.

FS-Curtis reserves the right to change the extended warranty program and/or requirements as deemed appropriate by the company.FS-Curtis reserves the right to refuse participation in the extended warranty program to any distributor and/or end customer of the compressor.
