EMAX ES10V080V1 10HP 2-Stage 80G Air Compressor

Previous Next

EMAX

EMAX ES10V080V1 10HP 2-Stage 80G Air Compressor

Name: EMAX ES10V080V1 10HP 2-Stage 80G Air Compressor
Brand: EMAX
SKU: EMXES10V080V1-03
Price: 6196.1 USD
Availability: InStock

0 review Write a Review

$6,196.10

(You save: $2,725.93 )

Product Code: EMXES10V080V1-03

Hurry up! Current stock:

Delivery Options: *

Delivery Notice: *

Quantity:

Product Details
Warranty Information
Product Features
Product Specs

Product Details

EMAX ES10V080V1 10HP 2-Stage 80G Air Compressor

📄 Download Installation Manual

Need help with installation? Our AI assistant has read this installation manual and can help you find the right page and walk you through each step.

Engineered and manufactured in the U.S.A., the EMAX ES10V080V1 10HP 2-Stage Industrial Air Compressor represents a breakthrough in industrial compressed air technology. Featuring the revolutionary Whisper 100 noise suppression system, this 80-gallon vertical tank compressor reduces stationary compressor noise levels by as much as 25% compared to conventional designs. Delivering 38 CFM @ 100 PSI with a maximum working pressure of 175 PSI, this unit is designed for demanding garage, farm shop, and industrial applications where performance, durability, and quiet operation are essential. Certified to UL, CSA, ASME, and ETL standards, this compressor is built for up to 70,000 hours of industrial use with proper maintenance.

Revolutionary Whisper Quiet Operation

The Whisper 100 noise suppression system was first conceived by EMAX engineers after feedback from competitor compressor users revealed widespread complaints regarding extreme noise levels in work environments. Stationary air compressor noise typically requires owners to incur the added expense of constructing a separate building or structure to house the compressor in an attempt to reduce workplace noise. The EMAX Whisper series eliminates this need entirely. This compressor can be installed and operated directly in all garage, farm shop, and industrial applications without requiring expensive and often inadequate separate enclosures.

The Whisper system dissipates compressor intake noise by channeling intake air through a series of baffle plates and pre-filter media within the silencer cabinet. As a result, piston intake noise is trapped and dissipated within the silencer structure. The system also acts as a secondary filtration stage for cleaner air delivery. The silencer assembly is already installed on the back of the tank with fabricated brackets designed for easy removal and a low profile.

Industrial Series Value & Performance

Our Industrial Series offers all the same quality and durability as our Plus series without the extra cost of added features. We offer this series so that anyone can afford to have an EMAX Compressor. This 10 HP 2-Stage Inline Single Phase Vertical 80 Gallon Piston Air Compressor features our low RPM pumps and automatic or continuous run functionality. This unit is SUPER COOL & SUPER QUIET!

Key Performance Highlights:

38 CFM @ 100 PSI – Powerful air delivery for demanding applications
800 RPM pump speed – Low RPM operation for extended life and reduced heat
230V single phase power – 40 amp running current, 60 amp breaker recommended
Built-in inter-cooler and after-cooler – Superior temperature management
Solid cast iron construction – Crankcase, cylinders, heads, and flywheel

The Heart of the System: EMAX Compressor Pump

At the core of our EMAX compressors is our pump. These pumps are SUPER quiet in operation and built to last! We start with a solid cast iron crankcase. Unlike some competitors' aluminum body crankcases, our solid cast iron crankcase ensures stable crankshaft alignment and handles significantly more workload under heavy load conditions.

Our APP4V1043TP pump model features a precision balanced solid cast iron crankshaft with Timken-Style stainless steel roller bearings on both the front and rear of the crankshaft to ensure smooth, efficient operation with less drag and reduced energy consumption. With a 2.5 quart oil capacity and built-in oil sight glass, maintenance monitoring is simple and straightforward.

Our pumps feature several key components that ensure durability and performance:

All steel connecting rods with replaceable rod bearing inserts. This allows our rods to be rebuilt! 99% of our competitors now use "throw-away" aluminum connecting rods in their pumps that have no re-build capability.
Re-usable oil filter for cost-effective maintenance
Oil pressure gauge for at-a-glance monitoring
Eligible for lifetime pump warranty
Removable 100% cast iron cylinders. These solid cast iron cylinders are more stable under heavy workloads and do not warp from heat. Most competitors use aluminum cylinders with a pressed-in sleeve that warp under extreme heat, limiting them to about a 40-50% duty cycle despite claiming 100%. Most pumps with aluminum cylinders have to be replaced in 1-2 years under heavy use. Our solid cast iron cylinders can "take the heat" and are designed to perform on heavy load demands.
All cast iron cylinder heads. Cast iron heads are more durable and dependable for trouble-free operation.
"Disc valve design" intake and exhaust valves. Disc valves have been proven to perform for over 100 years. Most competitors use "throw-away" reed valves which are not nearly as durable and can't be rebuilt. Our disc valves come right out of the top of the cylinder head where they can be serviced in minutes instead of hours like reed valves.
Top quality compression and oil rings. Our rings ensure performance with low oil carry over (1-5 PPM).
Precision ground pistons machined to tight tolerances ensuring low oil carry over.
Premium "non-absorbent" gaskets prevent oil seepage from pump.
All cast iron flywheel with built-in fan. The extra weight of our cast iron flywheel during run cycle gives the pump more "throw" on the compression stroke, resulting in fewer loads on the electric motor. Some manufacturers use aluminum flywheels that do not have the proper weight ratio to give the proper throw on the compression stroke.
Built-in head unloaders. These unloaders are built into the intake valve assembly on the compressor head and perform a valuable function. They unload or open the intake valves under constant run applications. This feature reduces internal pump heat from compression because the intake valve is held open throughout the unloading cycle. This allows fresh air to come into the cylinder chamber. Under the compression stroke, the unloader holds the intake valve open allowing the air to blow back out the intake filter. This fresh air absorbs heat out of the pump under heavy workloads.
Built-in inter-cooler and after-coolers. The inter-cooler allows air to be cooled between stages while the air-cooled after-cooler provides a second cooling stage that cools the air before it goes into the tank. Our after-cooler also includes an all copper main feed line from the pump into the tank.

Bottom Line: Not only do we have one of the highest quality, most durable compressor pumps in the industry, but we have one of the lowest RPM compressor pumps on the market. That's the EMAX difference!

Pump RPM is a critical factor in both performance and longevity. For that reason, on most of our compressors, we normally "GO BIG" by over-sizing our pumps and running them at lower RPMs than most manufacturers. Our bigger, 800 RPM pump can still yield high CFM output because both our bore and stroke are bigger. Not only do you get big CFM output, but the lower RPM operation also reduces friction and heat buildup to extend pump life significantly!

Industrial-Duty Electric Motor

This unit features a name brand ODP (Open Drip Protected) motor backed by a 5-year warranty. Most importantly, this is a low RPM motor (1,750 RPM) – most manufacturers now use higher RPM motors (3,450 RPM). 1,750 RPM motors run much cooler than 3,450 RPM motors because of the higher torque factor. They also yield low harmonic distortion, provide much higher torque in cold weather starting, and require less electricity under start conditions.

Additional Motor Features:

Large 1-3/8" output shaft
High quality ball bearings on the front and rear of the motor shaft
Large starting and running capacitors
1.15 Service Factor load – This means the motor can be pulled 15% over full load for more break horsepower
Dynamically balanced armature for low vibration levels

USA-Made ASME Air Tank

At EMAX we are always concerned about durability and your safety in everything we build. Along with this philosophy, our 80-gallon vertical air tanks are manufactured right here in the USA and are ASME code compliant in all 50 states including California. The tank features a 3/4" outlet and manual drain system for reliable operation. With dimensions of 38" L x 42" W x 72" H and weighing 810 lbs, this is a robust, stable platform for continuous industrial use.

Belt Drive System & Safety

We use taper lock style 2-groove pulleys (not single groove) and dual 2-groove, B-Style belts to drive our pumps. This combination is best for a couple of reasons.

First, dual belts ensure long belt life and yield low vibration which makes for smoother, more quiet operation because the dual belts do not have to be as tight as with a single belt setup. The tighter the belts (as with a single belt setup) the more load on the compressor pump and motor bearings which decreases the life of both.

Second, our taper lock pulleys are much better than a fixed bore pulley with a set screw. A taper lock design locks the pulley in position to the motor shaft allowing it not to loosen or move on the motor shaft.

We at EMAX Compressor are always concerned about durability and your safety. Our belt guards are no exception. Built right here in the USA with 13-gauge steel and premium grade expanded metal, we manufacture our belt guards to be tougher than any you will find in the industry today. For your safety, our belt guards are OSHA approved.

Premium Controls & Components

This unit features a prewired Condor starter and pressure switch built into one unit with an actuation-type diaphragm. We at EMAX Compressor use only top quality components on our compressors:

Top quality pressure switches with an adjustable screw which allows you to adjust your pressure higher or lower.
100% brass check valves with Teflon seating. All check valves on our compressors are all brass with Teflon seating. This reduces tank noise when the compressor is running because the Teflon seating is much quieter than other materials and insulates noise when valves are opening and closing during the compression stage.
100% brass ASME safety valves. For your safety all safety valves are 100% brass and comply to ASME code. Valves are preset and sealed for correct settings. In the event that your compressor would not turn off, our safety valves open keeping the compressor from building too high of a pressure level in the tank. This helps avoid the potential of tank rupture.
Top quality plumbing fittings are used to maintain proper sealing when connected to the tank.
High quality 100% brass ball valves are used for turning air on and off from the air receiver.
Extended tank water drain pipe plumbed out the front of the unit with a ¼" ball valve handle for easy tank draining. Eliminates the hassle of draining the tank with the typical petcock style drain under the tank.
Load-less starting. Thanks to built-in head un-loaders built into the intake valve assembly on the compressor head, "load-less" starting is built into this unit. This unloads the pump so the pump will not start under direct head pressure. Without this feature, motor damage can occur under starting cycle.

Looking for full specifications and features?
Check out the Product Specifications and Product Features tabs above for complete specs, dimensions, and detailed feature breakdowns.
