The BendPak VMP-7580V-601 V-Max Patriot air compressor combines leading-edge technology with the superior build quality you've come to expect from the world leader in automotive service equipment. Featuring an 80-gallon vertical tank and a powerful 7.5 HP low-RPM motor, this Made in USA compressor delivers 26 CFM at 175 PSI, making it ready for all your compressed air needs. Whether you're running a professional automotive shop, body repair facility, or industrial service center, the VMP-7580V-601 delivers the quality, performance, and reliability that demanding applications require.
Powerful Two-Stage Air Compressor, Proudly Made in USA
Unlock your shop's full potential with the V-Max Patriot VMP-7580V-601 Air Compressor. Featuring the rugged V-Max Patriot extreme-duty, four-cylinder pump design, the 7580V-601 is engineered to operate at maximum efficiency under all load conditions. This rugged, two-stage, oil-lubricated reciprocating air compressor with 100% cast-iron pumps will provide the quality and performance required for every air-intensive application—from automotive and body repair to manufacturing and industrial service.
Built to exacting standards right here in the USA, this compressor is UL, CSA, and ASME certified, ensuring it meets the highest safety and performance standards. With its continuous duty cycle and proven reliability, you can count on the VMP-7580V-601 to power through even the most demanding workloads without skipping a beat.
Energy-Efficient Motor & Quiet Operation
Like all members of the V-Max Patriot air compressor series, the VMP-7580V-601 has a 100% cast-iron V-Max Patriot pump with splash lubrication and a distinctive V-4 finned cylinder configuration. These enhancements result in total reliability and 360° cooling for superior heat dissipation. Plus, our heavy-duty, disc-type valves are dependable and accessible without even having to remove the cylinder head or perform other needlessly complicated valve maintenance procedures.
A built-in intercooler and air-cooled after-cooler chills the compressed air, reducing both heat and moisture due to condensation. But the best thing the 7580V-601 does is put out an extreme volume of air with remarkably little noise—just 78 dBA—thanks to a significantly slower 625 RPM pump speed and efficient two-stage design. The 7.5 HP energy-efficient motor operates at 1,750 RPM, delivering professional-grade performance while minimizing power consumption and operational costs.
Cast-iron pump and heads are more stable under heavy workloads and do not warp from heat like aluminum cylinders with pressed-in sleeves. The large surface area and cooling fins on cylinders, combined with the forced-air after-cooler, provide efficient heat dissipation for lower operating temperatures and dryer air. Your air compressor runs cooler, oil life is extended, and maintenance is reduced.
Vibration-Free, Long-Lasting Construction
This air compressor includes a set of four rugged anti-vibration pads (half-inch thick) to ensure there's virtually zero machine vibration during operation. The high-quality elastomer compound resists aging, compression set, water, and oil, keeping your compressor stable and your shop floor quiet.
The balanced flywheel and counterbalanced crankshaft result in nearly vibration-free operation, while dual drive belts require less belt tension, resulting in less load on pump bearings, longer belt life, and low vibration. A fully-enclosed belt guard provides added safety and keeps contaminants out. The oversized ductile iron crankshaft provides extra strength and longer wear, while high-density, die-cast aluminum alloy rods minimize reciprocating weight for smoother, more efficient operation.
Tapered roller main bearings provide full contact and support of the crankshaft, and needle-type piston pin bearings properly distribute bearing loads. Two compression rings and one oil control ring provide excellent oil control and high-efficiency air delivery. The rugged cast iron oil reservoir features a convenient sight gauge glass, large oil drain, and convenient fill cap, making routine maintenance quick and easy.
Advanced Cooling & Superior Efficiency
V-Max Patriot air compressors like the VMP-7580V-601 enjoy massive energy-efficient pumps that run at considerably slower speeds, resulting in lower operating temperature and maximum compressor efficiency. This is key. When making an air compressor purchase, you should always factor in the power consumption and maintenance cost into the overall price of the unit to determine the true cost of ownership. Electric power costs can add up considerably, based on the horsepower required to produce the necessary air. Producing more air per horsepower is exactly what the V-Max Patriot VMP-7580V-601 is designed to do.
The precision-balanced flywheel has forced-air fan blades for optimum compressor cooling and life. Integrated pressure unloader valves are built into the intake valve assembly on the compressor head, reducing internal pump heat from initial start-up compression. The proven air-cooled design is economical, reliable, and environmentally friendly, requiring no water hookups or additional plumbing.
It won't take long for you to realize how well the VMP-7580V-601, or any V-Max Patriot compressor, stacks up against the competition. Bottom line: BendPak V-Max Patriot air compressors produce more air per horsepower in a shorter amount of time. Nothing else comes close to their value.
Safety Features & Operator Protection
Safety is paramount. The VMP-7580V-601 is equipped with a magnetic starter that provides thermal overload protection and minimizes start loads, ensuring long life and trouble-free operation. An ASME-rated safety valve protects the compressor from overpressure and safeguards the operator. The automatic pressure switch provides auto start and stop functionality, while a pressure gauge with service valve keeps you informed of system performance at all times.
The 80-gallon vertical tank includes an electronic drain valve for easy condensate removal and features a 3/4" fitting outlet for flexible connection options. Corrosion-resistant tubing for coolers, separators, and valves ensures longer life and reduced maintenance.
Key Highlights
Made in USA with UL, CSA, and ASME certifications for proven quality and safety
7.5 HP energy-efficient motor delivers 26 CFM at 175 PSI with continuous duty cycle
Extra-quiet operation at 78 dBA thanks to low-RPM (625 RPM) two-stage V-4 pump design
100% cast-iron construction with splash lubrication and 360° finned cylinder cooling for maximum reliability
80-gallon vertical ASME tank with electronic drain valve and anti-vibration pads included
Easy Maintenance & Service Access
Readily accessible disc-valves do not require disassembly of compressor piping, allowing for easy accessibility and reduced maintenance cost and downtime. The oil sight glass lets you monitor lubrication levels at a glance, while the full pressure lubrication system ensures all critical components stay properly lubricated under all operating conditions.
With its belt-driven two-stage pump and solid cast-iron construction, the VMP-7580V-601 is built to last, minimizing long-term maintenance costs and maximizing uptime. The compressor's compact footprint—24" W x 72" D x 34" H—makes it easy to integrate into any shop layout, even in space-constrained environments.
Looking for full specifications and features?
Check out the Product Specifications and Product Features tabs
above for complete specs, dimensions, and detailed feature breakdowns.
Duration: From the date of purchase by original Purchaser or 60-24-12 months from the date of shipment by BendPak or whichever comes first.
Five Years (60-Months) Warranty on the compressor tank only
Two Years (24-Months) Warranty on the compressor pump only
One Year (12-Months) Warranty on operating components
One Year (12-Months) Labor Warranty on site or at factory
One Year (12-Months) Free-Shipping* on ground-freight charges related to warranty performance
Limited Warranty
1. Who gives this warranty (Warrantor): BendPak Inc., 1645 Lemonwood Dr., Santa Paula, CA 93060
2. Who receives this warranty (Purchaser): The original Purchaser (other than for purpose of resale)
3. What products are covered by this warranty: Any BendPak Air Compressor
4. What is covered under this warranty: manufacturer defects due to material and/or workmanship with the exceptions noted below.
5. What is not covered under this warranty:
a. Any failure that results from Purchaser’s abuse, neglect or failure to operate, maintain or service product in accordance with
instructions provided in the owner’s manual(s) supplied or any pre-delivery service, (assembly, oil, lubricants, adjustment etc.)
b. Items or service normally required to maintain the product, i.e. lubricants, oil, etc.
c. Items considered general wear parts such as rubber belts, hoses, etc. unless wear or failure is a direct result of manufacturer defect due to material and/or workmanship Other items not listed but considered general wear parts; a. Pump wear or valve damage caused by using oil not specified; b. Pump or valve damage caused by any oil contamination or by failure to follow proper oil maintenance guidelines; c. Ring wear or valve damage from inadequate filter maintenance
d. Any component damaged in shipment or any failure caused by installing or operating air compressor under conditions not in accordance with installation and operation guidelines or damaged by contact with tools or surroundings
e. Motor or pump failure caused by rain, excessive humidity, corrosive environments or other contaminants
f. Rusted tanks, including but not limited to rust due to improper drainage or corrosive environments. The five-year tank warranty applies to ASME air receivers only if they are installed on rubber anti-vibration pads or approved equivalent
g. Cosmetic defects that do not interfere with product functionality
h. Damage due to incorrect voltage or improper wiring
i. Any incidental, indirect, or consequential loss, damage, or expense that may result from any defect, failure, or malfunction of BendPak Inc. product
j. All electrical components are guaranteed for one year against defects in workmanship and/or materials when the lift is installed
and used according to specifications
6. Responsibilities of Warrantor under this warranty: Repair or replace, at Warrantor’s option, component which is defective, has malfunctioned and/or failed to conform within duration of the warranty period. BendPak Inc. will pay reasonable labor costs for the first 12 months only
7. Responsibilities of Purchaser under this warranty:
a. Provide dated proof of purchase and maintenance records
b. In some cases, components may be required to be shipped to the nearest BendPak Authorized Service Center. Freight costs, after 12-months, must be borne by the Purchaser.
c. Use reasonable care in the operation and maintenance of the products as described in the owner’s manual(s).
8. When Warrantor will perform repair or replacement under this warranty: Repair or replacement will be scheduled and serviced according to the normal work flow at the servicing location, and depending on the availability of replacement parts.
*Free-shipping applies to direct shipping points within the 48 continental United States. Rural area shipping surcharge may apply for remote
addresses.
Limitation of Liability
BendPak/Ranger shall have no obligation pursuant to this Warranty with respect to products which in our sole judgment have been altered damaged, misused, abused, badly worn, lost or improperly maintained. This Warranty is null and void if the customer or any other person other
than an authorized representative of BendPak/Ranger has made any attempt to service or modify the tool prior to its return to BendPak/Ranger under this Warranty. In no event will either party be liable for any damage caused by the other party's failure to fulfill its responsibilities under
these terms and conditions. In no event will either party be liable for any lost profits, lost savings, incidental damage, or other economic consequential damages. All expressed and implied warranties, including the implied warranties of merchantability and fitness for a particular
purpose, are limited in duration to the coverage period. No warranties, expressed or implied, will apply after this period. BendPak may modify these terms and conditions at any time by either providing the customer with written notice or posting such revised terms on www.bendpak.com. Such revised terms shall be effective thirty days from the date of such written notice or posting.
