The Autel IA1000TDT package represents the pinnacle of automated alignment and ADAS calibration technology for professional automotive service centers. This comprehensive system combines robotic precision with advanced diagnostic power to deliver industry-leading accuracy to 0.02-degrees for both four-wheel alignment and static/dynamic ADAS calibrations. Powered by the included MaxiSYS Ultra S2 advanced diagnostics tablet with MaxiFlash VCMI2 communication device and complete IA1000 alignment and ADAS software, this package provides extensive coverage for U.S., Asian, and European vehicles.
What sets the IA1000TDT apart is its integration of three 27-inch attachable monitors and Autel's digital LDW target kit, enabling one-step robotic and vertical target placement that dramatically reduces manual setup time and eliminates positioning errors. The system features six high-definition cameras and precision-engineered wheel clamps working in concert with automatic pitch, roll, yaw, and front-to-back fine-tuning robotic adjustments to ensure unmatched accuracy while minimizing human error. The included 24-inch touchscreen display attaches directly to the frame unit for intuitive operation and streamlined workflow.
The IA1000 frame unit is engineered for comprehensive vehicle service capabilities. With robotic forward-facing camera target positioning, laser-guided ACC, blind spot calibrator, and AVM mat placement with unlevel floor compensation, this system handles the full spectrum of modern vehicle calibration requirements. The unit can perform both four-wheel alignment services and complex ADAS component calibrations on the same platform, maximizing your shop's efficiency and revenue potential.
The included MaxiSYS Ultra S2 tablet delivers powerful processing and extensive vehicle coverage right out of the box. Preloaded with IA1000 alignment software and both static and dynamic ADAS calibration coverage, the Ultra S2 provides comprehensive diagnostic capabilities alongside alignment and calibration functions. The MaxiFlash VCMI2 6-in-1 communication and measurement device ensures fast, reliable connections to virtually any vehicle make and model.
The digital target system represents a major advancement in calibration workflow efficiency. The three included 27-inch attachable monitors display Autel digital LDW targets for Mercedes-Benz, Honda, Nissan, Infiniti, Toyota, Mazda, Mitsubishi, Maserati, Hyundai, Kia, and Subaru vehicles. This eliminates the need to purchase, store, and manage dozens of physical target boards. One-step robotic placement ensures perfect positioning every time, while the system automatically handles pitch, roll, yaw, and positioning adjustments that would otherwise require time-consuming manual measurements and repositioning.
This complete package includes everything your shop needs to perform professional alignment and ADAS calibration services:
The IA1000TDT is compatible with additional Autel MaxiSYS tablets (with IA1000 ADAS Upgrade software) and physical Autel targets, patterns, and calibration components available separately, allowing you to expand capabilities as your business grows.
Looking for full specifications and features?
Check out the Product Specifications and Product Features tabs above for complete specs, dimensions, and detailed feature breakdowns.
The IA1000TDT system includes a one-year limited warranty and one year of free Ultra S2 software updates to ensure your equipment stays current with the latest vehicle coverage and calibration procedures.
