The Nationwide NW-9KACD Two-Post Floor Plate Lift is a powerful and dependable solution for professional automotive shops, delivering a 9,000 lb. lifting capacity for cars, SUVs, and light-duty trucks. Engineered by Best Buy Auto Equipment, this lift combines rugged construction with advanced safety features to ensure long-lasting performance in high-volume service environments.
What sets the NW-9KACD apart is its remarkable flexibility. Featuring dual metric arms with both asymmetric and symmetric 3-stage front arms, this lift allows technicians to position vehicles precisely for optimal access to undercarriage components. The three-stage front arms extend from 25.5" to 44.25", while the rear arms reach from 39.5" to 57.5", accommodating everything from compact sedans to full-size trucks with ease.
Built with dual hydraulic chain-drive cylinders and automatic arm restraints, the NW-9KACD provides smooth, stable operation with every lift cycle. The direct drive cylinder attaches directly to the carriage for enhanced lift stability and long-term durability, ensuring your investment performs reliably for years to come.
Safety is paramount in any professional shop. The Nationwide NW-9KACD is equipped with multiple layers of protection to give technicians confidence during every lift operation. A dual-point manual safety release gives operators precise control, while the ladder-style safety latch system engages in secure 3" increments starting at 16" from the ground for reliable protection during lifting.
The safety latch automatically re-engages when the lift ascends and must be manually disengaged to lower, adding an extra layer of operator safety. A padded shut-off bar provides added protection by preventing accidental overhead contact, while heavy-duty rubber padded door guards protect vehicle doors from scratches and dents during service—a detail your customers will appreciate.
Maximum Lifting Height: The NW-9KACD reaches 72" at standard height and extends to an impressive 77.75" with stack adapters, providing exceptional working clearance for technicians. Raising time is just 55 seconds, keeping your service bays efficient and productive.
The NW-9KACD is designed with generous clearances that accommodate a broad range of vehicles and make daily operations smoother. With 96" of drive-through clearance between arms and 115.75" between posts, you'll have no trouble maneuvering vehicles into position, even larger trucks and SUVs.
The lift's adjustable screw pads include stackable adapters (1.5" and 5") for customized lifting height at various contact points. The drop-in pad height adjusts from 4" to 10", giving technicians the flexibility to safely lift vehicles with different ground clearances and frame configurations. A complete set of drop-in height adapters is included with every lift.
The Nationwide NW-9KACD is built with heavy-duty materials and precision engineering to withstand the demands of a busy professional shop. Every component is designed for longevity, from the robust column height of 145.4" to 149.3" to the reinforced carriage system.
With a maximum load per arm of 2,250 lbs, the lift distributes weight evenly and safely. The total width (outside base plate) measures 139.5", providing a stable footprint without consuming excessive floor space. The overhead switch is positioned at 136.75" to 140.75" from the floor for convenient access.
This two-post lift is powered by a standard 220V/60Hz/1PH supply and backed by direct manufacturer support, ensuring confidence and peace of mind for professional technicians.
Important Installation Requirement:
Requires a minimum concrete thickness of 4.25" (108mm) at 3,000 PSI (207 bar). Improper installation may result in serious injury or damage. Please verify concrete specifications before installation.
Looking for full specifications and features?
Check out the Product Specifications and Product Features tabs above for complete specs, dimensions, and detailed feature breakdowns.
WARNING: This product contains certain metals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Warranty
This item is warranted for five (5) years on structural components and one (1) year on air or electric hydraulic power units, pneumatic power units, and major components from date of invoice. Wear items are covered by 6 months. Hydraulic cylinder is covered for 1-year warranty.
This LIMITED warranty policy does not include a labor warranty.
NOTE: ALL WARRANTY CLAIMS MUST BE PRE-APPROVED BY THE MANUFACTURER TO BE VALID.
The Manufacturer shall repair or replace at their option for this period those parts returned to the factory freight prepaid, which prove after inspection to be defective. This warranty will not apply unless the product is installed, used and maintained in accordance with the Manufacturers installation, operation and maintenance instructions.
This warranty applies to the ORIGINAL purchaser only, and is non-transferable. The warranty covers the products to be free of defects in material and workmanship but, does not cover normal maintenance or adjustments, damage or malfunction caused by: improper handling, installation, abuse, misuse, negligence, carelessness of operation or normal wear and tear. In addition, this warranty does not cover equipment when repairs or alterations have been made or attempted to the Manufacturer’s products.
THIS WARRANTY IS EXCLUSIVE AND IS LIEU OF ALL OTHER WARRANTIES EXPRESSED OR IMPLIED INCLUDING ANY IMPLIED WARRANTY OR MERCHANTABILITY OR ANY IMPLIED WARRANTY OF FITNESS FROM A PARTICULAR PURPOSE, AND ALL SUCH IMPLIED WARRANTIES ARE EXPRESSLY EXCLUDED. THE REMEDIES DESCRIBED ARE EXCLUSIVE AND IN NO EVENT SHALL THE MANUFACTURER, NOR ANY SALES AGENT OR OTHER COMPANY AFFILIATED WITH IT OR THEM, BE LIABLE FOR SPECIAL CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR THE BREACH OF OR DELAY IN PERFORMANCE OF THIS WARRANTY. THIS INCLUDES, BUT IS NOT LIMITED TO, LOSS OF PROFIT, RENTAL OR SUBSTITUTE EQUIPMENT OR OTHER COMMERCIAL LOSS.
PRICES: Prices and specifications are subject to change without notice. All orders will be invoiced at prices prevailing at time of shipment. Prices do not include any local, state or federal taxes.
RETURNS: Products may not be returned without prior written approval from the Manufacturer.
DUE TO THE COMPETITIVENESS OF THE SELLING PRICE OF THESE LIFTS, THIS WARRANTY POLICY WILL BE STRICTLY ADMINISTERED AND ADHERED TO.
