The Nationwide NW-10KACD two-post floor plate lift delivers reliable, high-performance lifting with a 10,000 lb. capacity—ideal for cars, SUVs, and light trucks in professional automotive shops. Built by Best Buy Auto Equipment, this rugged lift is engineered to meet strict quality standards and deliver lasting durability in busy shop environments. With its dual metric arms offering both asymmetric and symmetric lifting configurations, the NW-10KACD provides exceptional versatility for a wide range of vehicles and service applications.
Featuring dual hydraulic chain-drive cylinders and automatic arm restraints, this lift ensures stable, secure operation every time. A dual-point manual safety release gives technicians added control and confidence during vehicle servicing. The lift's innovative three-stage front arms and extendable rear arms accommodate varying wheelbases and vehicle types, while the direct drive cylinder design—where the cylinder attaches directly to the carriage—provides enhanced stability and smooth lifting performance.
The safety latch system on the NW-10KACD operates similarly to an extension ladder for reliable, intuitive protection. The safety latch remains in contact with the rack as the lift ascends and automatically drops into place as the lift rises. The safety latch engages the rack in 3-inch (76mm) increments, starting at approximately 16 inches (406mm) from the ground, ensuring multiple secure locking positions throughout the lift's travel range.
The locking latch must be manually disengaged for the lift to descend, giving technicians full control over lowering operations. The latch is released by pulling the release cable, which raises the latch up off the latch rack. Once the raise button is pressed, the latch will automatically re-engage after approximately 3 inches (76mm) of travel, providing continuous protection during lifting operations.
Additional safety features include a padded shut-off bar and heavy-duty rubber door guards that protect both vehicles and shop personnel. These thoughtful design elements reduce the risk of damage during vehicle positioning and enhance overall workplace safety.
What sets the NW-10KACD apart is its dual metric arm system that seamlessly operates in both asymmetric and symmetric modes. The innovative three-stage arms on the front provide exceptional reach flexibility, extending from 25.5 inches to 44.25 inches, while the rear arms extend from 39.5 inches to 57.5 inches. This extensive adjustability makes it easy to position lift points precisely where needed for different vehicle designs and weight distributions.
The lift offers an impressive 96-inch drive-through clearance between arms and 115.75 inches between posts, providing ample room for positioning vehicles and working comfortably underneath. With a maximum lifting height of 72 inches (or 77.75 inches with adapters), technicians gain excellent undercarriage access for comprehensive service and repair work.
The screw-style adjustable pads with stack adapters (1.5-inch and 5-inch) offer precise height adjustment from 4 inches to 10 inches, accommodating various vehicle lift points and frame configurations. The included set of drop-in height adapters further enhances versatility, making this lift suitable for everything from low-profile sports cars to higher-clearance SUVs and light trucks.
The Nationwide NW-10KACD is designed for the demands of professional automotive service facilities. Its robust construction and thoughtful engineering deliver years of reliable performance, while the 55-second rise time keeps your bay productive and efficient. The lift operates on standard 220V/60Hz/1-phase power, making installation straightforward in most shop environments.
With column heights of 145.4 inches to 149.3 inches and a total width of 139.5 inches (outside base plate), the lift fits well in standard ceiling heights while maximizing lifting capability. The floor to overhead switch measures 136.75 inches to 140.75 inches, ensuring safe and convenient operation. Each arm supports a maximum load of 2,500 lbs, providing balanced weight distribution across the lift platform.
Looking for full specifications and features?
Check out the Product Specifications and Product Features tabs above for complete specs, dimensions, and detailed feature breakdowns.
Concrete Requirements: This lift requires a minimum concrete thickness of 4.25 inches (108mm) at 3,000 PSI (207 bar) for safe installation and operation.
Improper installation may result in serious injury or damage. Please verify concrete specifications before installation and consult the installation manual for complete anchoring requirements.
⚠ California Proposition 65 Warning:
This product contains certain metals known to the State of California to cause cancer and birth defects or other reproductive harm. For more information, visit www.P65Warnings.ca.gov
Warranty
This item is warranted for five (5) years on structural components and one (1) year on air or electric hydraulic power units, pneumatic power units, and major components from date of invoice. Wear items are covered by 6 months. Hydraulic cylinder is covered for 1-year warranty.
This LIMITED warranty policy does not include a labor warranty.
NOTE: ALL WARRANTY CLAIMS MUST BE PRE-APPROVED BY THE MANUFACTURER TO BE VALID.
The Manufacturer shall repair or replace at their option for this period those parts returned to the factory freight prepaid, which prove after inspection to be defective. This warranty will not apply unless the product is installed, used and maintained in accordance with the Manufacturers installation, operation and maintenance instructions.
This warranty applies to the ORIGINAL purchaser only, and is non-transferable. The warranty covers the products to be free of defects in material and workmanship but, does not cover normal maintenance or adjustments, damage or malfunction caused by: improper handling, installation, abuse, misuse, negligence, carelessness of operation or normal wear and tear. In addition, this warranty does not cover equipment when repairs or alterations have been made or attempted to the Manufacturer’s products.
THIS WARRANTY IS EXCLUSIVE AND IS LIEU OF ALL OTHER WARRANTIES EXPRESSED OR IMPLIED INCLUDING ANY IMPLIED WARRANTY OR MERCHANTABILITY OR ANY IMPLIED WARRANTY OF FITNESS FROM A PARTICULAR PURPOSE, AND ALL SUCH IMPLIED WARRANTIES ARE EXPRESSLY EXCLUDED. THE REMEDIES DESCRIBED ARE EXCLUSIVE AND IN NO EVENT SHALL THE MANUFACTURER, NOR ANY SALES AGENT OR OTHER COMPANY AFFILIATED WITH IT OR THEM, BE LIABLE FOR SPECIAL CONSEQUENTIAL OR INCIDENTAL DAMAGES FOR THE BREACH OF OR DELAY IN PERFORMANCE OF THIS WARRANTY. THIS INCLUDES, BUT IS NOT LIMITED TO, LOSS OF PROFIT, RENTAL OR SUBSTITUTE EQUIPMENT OR OTHER COMMERCIAL LOSS.
PRICES: Prices and specifications are subject to change without notice. All orders will be invoiced at prices prevailing at time of shipment. Prices do not include any local, state or federal taxes.
RETURNS: Products may not be returned without prior written approval from the Manufacturer.
DUE TO THE COMPETITIVENESS OF THE SELLING PRICE OF THESE LIFTS, THIS WARRANTY POLICY WILL BE STRICTLY ADMINISTERED AND ADHERED TO.
