Built for the Modern Shop: EVs, Tall Cargo Vans & Heavy Vehicles
The BendPak 10APX-181 PRO Series is the ultimate solution for shops tackling the evolving demands of today's automotive landscape. Designed to handle high-roof cargo vans, electric vehicles, and larger commercial trucks, this lift features a towering 181" overhead beam height—one of the tallest in the industry—delivering exceptional clearance for even the most challenging vehicles.
With a robust 10,000-lb. lifting capacity, ALI certification, and a maximum rise of 75.5" (1,918 mm), this lift is engineered for serious work. The exclusive Low-Pro™ arms with dropped-end pad receivers and Bi-Metric™ arm design provide unmatched flexibility for both symmetric and asymmetric lifting. Whether you're servicing heavy-duty EVs with reinforced battery chassis or lowered performance vehicles, the 10APX-181 PRO delivers the versatility, strength, and safety modern technicians demand.
This complete package includes the WSA-100 Work Station Package with four 110V GFI outlets, air service with regulator/filter and oiler, plus a full set of frame cradle pads, medium (2.5") and tall (5") adapters, and an adapter holder for convenient storage.
Empowering the Future of EV Service
Say goodbye to cramped workspaces and uncomfortable service positions. The BendPak 10APX-181 PRO Series delivers a premium, ergonomic lifting experience engineered for the future of automotive service. As the industry shifts toward electric, hybrid, and solar-powered vehicles, heavier chassis configurations—packed with additional batteries, reinforced frameworks, upgraded suspension, and protective armor—demand stronger, smarter equipment.
BendPak's PRO Series was specifically engineered to meet these new challenges head-on. Using high tensile-strength steels for all critical load-bearing components, this lift ensures maximum durability and safety even under the most demanding workloads. The added weight and complexity of EVs stress lift components—especially in two-post lifts—but the 10APX-181 PRO is built to handle it with ease.
The oversized 59" tall carriages provide superior strength and stability, while dual hydraulic direct-drive cylinders deliver smooth, synchronized lifting in approximately 45 seconds to full rise. With noise levels below 70 dB, technicians can work comfortably and efficiently without distraction. This lift combines simplicity with smart design, ensuring minimal maintenance costs and maximum productivity.
Flexible Installation: Wide or Narrow Configuration
The PRO Series offers the versatility of both wide and narrow installation configurations in a single, fully customizable package. Choose from a 135" or 145" overall width, with corresponding inside column clearances of 108.5" or 118.5", and drive-thru clearances of 97.5" or 107.5". This flexibility ensures you can adapt the lift to your shop's specific layout, maximizing workspace efficiency and vehicle accommodation.
The expandable top beam adjusts to accommodate wide or narrow drive-thru needs, while the ultra-wide column spacing provides superior under-car access for technicians working on trucks, vans, SUVs, and sports cars alike. The Bi-Metric™ arms effortlessly handle both symmetric and asymmetric lifting with precision, making vehicle positioning fast and intuitive.
Automatic Swing Arm Restraint System (ASARS)
The revolutionary Automatic Swing Arm Restraint System (ASARS) is a game-changer for lift safety and stability. This patented system, constructed with heavily forged steel, locks lift arms securely in place with an impressive load-holding force of over 2,000 pounds. The result is unmatched stability, preventing unintended swing-arm movement during lifting and vehicle service operations.
Featuring a full 360-degree load-holding grip, the patented forged-steel design delivers superior holding force with precision non-shifting action. The quick-release operator lever allows for instant clamping release when you need to reposition arms. This adaptive system requires minimal operator involvement, providing unmatched security when lifting full-sized trucks, SUVs, or heavy electric vehicles onto the lift.
The 10APX-181 PRO features revolutionary and patented triple-telescoping swing arms specifically tailored for varying vehicle lifting points. Unlike traditional two-post lift arms, 10AP series arms retract shorter and extend farther, offering lift operators a multitude of arm positioning options—it's like having the best of all worlds in one lift.
The innovative three-stage arms achieve more telescoping movement due to their patented nesting feature that results in greater retraction and farther reach. The front arms reach a maximum of 50" (1,270 mm) and retract to a minimum of 24.5" (622 mm), while the rear arms extend to 59.25" (1,505 mm) and retract to 32" (813 mm). Inner sliding arm movement is no longer impeded by arm end plates, tube closeouts, or even the arm pivot pin itself—the inner tubes retract fully through the back of the arm assembly and even beyond the arm pin, resulting in unmatched retraction and extension.
This design is perfect for accommodating a wide variety of vehicle sizes and lift point configurations, from compact cars to extended-wheelbase cargo vans. Each arm supports a maximum load of 2,500 lbs. (1,134 kg), ensuring balanced, secure lifting across all four contact points.
Low-Pro™ Swing Arms: Access the Inaccessible
BendPak's exclusive Low-Pro™ swing arms feature telescoping channels with a shorter profile and a dropped-end pad receiver, resulting in better serviceability on lowered chassis-height vehicles. They access hard-to-reach lift points with less hindrance, providing increased versatility and less chance of damage to vehicle side skirts, running boards, or ground effects.
With a minimum pad height of just 4" (102 mm), these arms are engineered for modern low-profile performance vehicles and EVs with complex undercarriage designs. The double-telescoping screw pads offer 2" (51 mm) of vertical adjustment, while varying height stackable adapters (included: medium 2.5" and tall 5") provide greater vertical pad placement for precise and safe vehicle support. The frame cradle pads (set of 4 with 60mm pin) ensure stable, secure contact with the vehicle's designated lift points.
Comprehensive Safety Features
Safety is at the heart of every BendPak design. The 10APX-181 PRO is equipped with a comprehensive suite of safety features that protect both the operator and the vehicle. A padded overhead safety shutoff bar prevents over-travel, while dual hydraulic direct-drive cylinders ensure smooth, synchronized lifting action.
The lift features safety locks in each column spaced every 3", providing secure holding positions at multiple heights throughout the lift range. The single-point safety release simplifies operation, allowing the technician to disengage all locks from one convenient location. This design enhances workflow efficiency and reduces operator fatigue during busy service days.
The system is powered by an electric/hydraulic HVLP power system driven by a 220 VAC / 60 Hz / 1-Phase motor. A 3/8" (10 mm) high-strength multi-strand galvanized steel equalizing cable synchronizes the columns for perfectly balanced lifting, while oversized cable sheave diameters reduce cable fatigue and extend service life.
The self-lubricating Dura-Glide UHMW polyethylene bearing system ensures smooth, quiet operation with minimal friction and wear over time. The durable powder coat finish protects against corrosion and shop chemicals, maintaining a professional appearance and long service life even in demanding environments.
WSA-100 Work Station Package Included
This complete lift package includes the WSA-100 Work Station, a premium accessory that transforms your lift into a fully integrated service station. The work station is easy to install and adapts to any two-post or four-post lift, providing convenient access to power and air service right where you need it.
Key features of the WSA-100 include:
Four 110V GFI outlets equipped with 20 amp industrial GFI protection
Electrical outlets located above the air service to prevent moisture damage and tangling
Air service through 2 outlets: one lubricated for tire inflation and one for pneumatic tools
Air service filter element and lubricator filler port are easily accessible
Nickel-plated ball valve shutoff for precise air control
Regulator/filter with pressure gauge for air quality and pressure monitoring
Storage hooks for hose and tools, keeping your workspace organized
Powder-coated finish for durability and long life
The work station keeps tools, air hoses, and power cords organized and within easy reach, streamlining your workflow and maximizing productivity during every service job.
Key Highlights
181" overhead beam height for high-roof cargo vans and tall commercial vehicles
10,000-lb. capacity with ALI certification for safe, compliant operation
75.5" maximum rise (89" with pad and tall adapter) for exceptional under-vehicle access
Patented triple-telescoping arms with extreme retraction and extension range
Automatic Swing Arm Restraint System (ASARS) with over 2,000 lbs. holding force
Low-Pro™ arms with 4" minimum pad height for low-profile and EV service
WSA-100 Work Station Package with power, air service, and tool storage included
Expandable top beam for wide (145") or narrow (135") installation configurations
Looking for full specifications and features?
Check out the Product Specifications and Product Features tabs
above for complete specs, dimensions, and detailed feature breakdowns.
Note: The design, material, and specifications are subject to change without notice. Not all BendPak lift models meet the standards as prescribed by ANSI/ALI ALCTV (Current Edition) or ANSI/UL 201. Consult www.autolift.org for a complete list.
LIMITED WARRANTY. Subject to the limitations of set forth below, Warrantor warrants that the Product sold hereunder conform to Warrantor's
published specifications. WARRANTOR MAKES NO REPRESENTATION OR WARRANTY OF ANY OTHER KIND, EXPRESS OR IMPLIED, WITH RESPECT TO
THE GOODS, WHETHER AS TO MERCHANTABILITY, FITNESS FOR A PARTICULAR PURPOSE OR ANY OTHER MATTER
Duration: From the date of purchase by the original Purchaser or 60-24-12 months from the date of shipment by BendPak or whichever comes first.
Five Years (60-Months) Warranty on the lift structure
Two Years (24-Months) Warranty on the hydraulic cylinder(s) and power unit
One Year (12-Months) Warranty on operating components
One Year (12-Months) Warranty on electrical components (excluding power unit)
One Year (12-Months) Labor Warranty on site or at factory*
One Year (12-Months) Free-Shipping** on ground-freight charges related to warranty performance
Limited Warranty
Who gives this warranty (Warrantor): BendPak Inc., 1645 lemonwood dr. Santa Paula, CA 93060
Who receives this warranty (Purchaser): The original Purchaser (other than for purpose of resale)
What products are covered by this warranty: Any BendPak Two-Post or Four-Post car lift***
What is covered under this warranty: manufacturer defects due to material and/or workmanship with the exceptions noted below.
What is not covered under this warranty:
Any failure that results from Purchaser’s abuse, neglect or failure to operate, maintain or service product in accordance with instructions provided in the owner’s manual(s) supplied
Any damage caused by overloading Product beyond rated capacity
Items or service normally required to maintain the product, i.e. lubricants, oil, etc.
Items considered general wear parts such as rubber pads, lifting cables, etc. unless wear or failure is a direct result of manufacturer defect due to material and/or workmanship
Any component damaged in shipment or any failure caused by installing or operating lift under conditions not in accordance with installation and operation guidelines or damaged by contact with tools or surroundings
Motor or pump failure caused by rain, excessive humidity, corrosive environments or other contaminants
Rusted components due to improper maintenance or corrosive environments
Cosmetic defects that do not interfere with product functionality
Damage due to incorrect voltage or improper wiring
Any failure that results from improper installation or use not according to specifications
Damage caused by disasters such as fire, flood, wind, and lightning
Damage caused by unauthorized attachments or modifications
Responsibilities of Warrantor under this warranty: Repair or replace, at Warrantor’s option, component which is defective, has malfunctioned and/or failed to conform within duration of the warranty period. BendPak Inc. will pay reasonable labor costs for the first 12 months only
Responsibilities of Purchaser under this warranty:
Provide dated proof of purchase and maintenance records
In some cases, components may be required to be shipped to the nearest BendPak Authorized Service Center. Freight costs, after 12-months, must be borne by the Purchaser.
Use reasonable care in the operation and maintenance of the products as described in the owner’s manual(s).
Immediately upon receipt of the Product, Purchaser shall inspect the same. Any claim for shortage must be made within ten days after Purchaser's receipt. All other claims, including claims for alleged defective Product, must be made within fifteen days after Purchaser learns of the facts upon which such claim is based, but in no event later than the applicable one, two or five year period specified above for the specified component(s). All claims not made in writing and received by Seller within the time periods specified above shall be deemed waived. With respect to any defects incapable of discovery until in use, all claims for any
damages or losses as a result of such defects shall be deemed waived unless made in writing and received by Seller within fifteen days after Purchaser learns of the alleged defect giving rise to the claim and after the expiration of said periods, but in no event later than the applicable one, two or five year period specified above for the specified component(s). Purchaser expressly assumes all liability for all such damages or losses, irrespective of any use which shall have taken place or whether the alleged defect shall have occurred or been discovered prior to expiration of such periods.
When Warrantor will perform repair or replacement under this warranty: Repair or replacement will be scheduled and serviced according to the normal work flow at the servicing location, and depending on the availability of replacement parts.
*As determined by Warrantor in its sole discretion**Free-shipping applies to direct shipping points within the 48 continental United States.
Rural area shipping surcharge may apply for remote addresses. ***For all BendPak brand Two-Post or Four-Post Vehicle Service Lifts
(excluding specialty lifts, high rise, commercial parking, material handling, or models for particular purpose) manufactured on or following
1/1/2011.
