When your shop demands heavy-duty lifting capacity for both long wheelbase trucks and passenger vehicles, the Atlas® Platinum PVL15 delivers professional-grade performance with ALI CERTIFIED reliability. This 15,000 lb capacity commercial overhead two-post lift stands out with its extra tall 174 1/2" overall height and extra wide 148" floor width, providing the versatility your operation needs for a diverse vehicle lineup. Built with dual direct-drive hydraulic cylinders, symmetric arms, and a professional-grade arm lock restraint system, the PVL15 combines exceptional strength with precision engineering.
Powered by the premium ALLY Hydraulic AL2300 Power Unit, this lift benefits from advanced engineering that minimizes heat generation and maintains constant torque throughout the lifting cycle. MET Laboratories Inc. certified for electrical compliance in both the United States and Canada, the AL2300 features extra heavy-duty armatures and enhanced motor windings with increased silver metal content in wires and connections—delivering superior reliability and backed by an industry-leading two-year limited warranty.
Click here to view or download the lift inspection guide.
The Atlas Platinum PVL15 is engineered for shops that need maximum versatility. With an overall height of 174 1/2" (14' 6 1/2"), this lift can be further extended by an additional 2 feet with the optional Height Extension Kit, making it ideal for accommodating taller trucks and commercial vehicles. The 135" outside column-to-column clearance and 107 1/2" drive-thru clearance provide ample room for a wide variety of vehicles, while the maximum lift height with truck adapters reaches 87 1/2", giving technicians excellent working clearance underneath even the largest pickups and SUVs.
The lift's symmetric arm design paired with padded carriages ensures secure, damage-free lifting, while the professional-grade arm lock restraint system provides multiple locking positions for enhanced safety. Heavy-duty 3/8" equalization cables ensure smooth, balanced operation, and the dual direct-drive hydraulic cylinders deliver powerful, consistent performance with an 80-second lifting time. The minimum arm height of just 6 inches allows for easy positioning under low-profile vehicles.
The PVL15 arrives ready for installation with everything you need. A complete 8-piece truck adapter set and 4 screw-up frame adapters are included free, giving you the flexibility to lift trucks, SUVs, and passenger cars right out of the box. Four 5-inch and four 10-inch adapter extensions provide additional height options for various frame configurations. All necessary mounting hardware is included, streamlining your installation process.
The lift requires 220V single-phase power with a 30 amp breaker and operates on 3-5 gallons of AW32/AW46 hydraulic oil (not included). The robust 8" x 14 1/2" columns provide exceptional structural strength, and with a unit weight of 2,600 lbs, the PVL15 is built to withstand the rigors of daily commercial use.
Looking for full specifications and features?
Check out the Product Specifications and Product Features tabs
above for complete specs, dimensions, and detailed feature breakdowns.
At the heart of the Atlas Platinum PVL15 is the advanced ALLY AL2300 Power Unit—a testament to superior hydraulic engineering. This premium unit distinguishes itself with extra heavy-duty armatures and enhanced motor windings that feature increased silver metal content in the wires and connections. This advanced construction dramatically reduces heat generation during operation, allowing the power unit to maintain constant torque throughout the entire lifting process. The result is smoother, more reliable performance and extended component life. View detailed AL2300 power unit specs and parts list.
Certified by MET Laboratories Inc. for electrical compliance in the United States and Canada, the AL2300 meets rigorous safety and performance standards. This certification, combined with the power unit's robust construction and backed by an industry-leading two-year limited warranty, gives you confidence in your investment for years to come.
Warranty Information
To View Atlas® Automotive Equipment PVL-15 Warranty Click Here
