The Atlas® 9OHSC (SS) Symmetric 2 Post Lift is the perfect choice for smaller commercial repair facilities or dedicated "Mr. Homeowners" who demand the highest quality at the absolute best price. This is a TRUE 9,000 lb. capacity two post above ground lift that offers exceptional value without compromise. Engineered and manufactured to lift vehicles ranging from Smart Cars® to a Suburban®, the 9OHSC delivers professional-grade performance with an overhead, open-floor design that maximizes your workspace efficiency.
Built with a single-piece 11' 10" formed column and an extra-long carriage, the Atlas® 9OHSC provides maximum column and arm strength to safely lift and support heavy vehicles. The single-piece column design eliminates weak points and ensures years of trouble-free service, though it does require a minimum 12-foot ceiling height for installation. With dual hydraulic chain-drive cylinders, automatic arm restraints, and a convenient single-point lock release, this lift combines robust construction with user-friendly operation.
Key Highlights
9,000 lb. capacity – handles a wide range of vehicles from compact cars to full-size SUVs and light trucks
Overhead, open-floor design – symmetric configuration maximizes workspace and drive-thru clearance of 100 ½"
Single-piece column construction – eliminates welds and weak points for maximum strength and reliability
3-stage front arms and 2-stage rear arms – offers flexible positioning with a minimum arm height of just 4 inches
Free 12-piece truck adapter set included – ready to lift trucks and larger vehicles right out of the box
Maximum lift height of 87 ¾" with adapters – provides ample clearance for working underneath vehicles
Professional Design Features
The Atlas® 9OHSC is packed with features that enhance safety, durability, and ease of use. The automatic arm restraints and single-point lock release system make operation straightforward and secure. Rubber guards on carriages protect vehicle frames and pinch welds during lifting. The dual hydraulic chain-drive cylinder system ensures smooth, balanced lifting every time.
With an overall floor width of 133 ½" and an inside column clearance of 109 ½", this lift accommodates a wide variety of vehicle sizes. The 8" x 9 3/8" columns are constructed from 5mm thick steel, providing exceptional structural integrity. The lift ships at 1,430 lbs. and includes all necessary mounting hardware plus the 12-piece truck adapter set featuring adapters in 2", 3", and 6" heights.
What's Included
Complete Atlas® 9OHSC-SS two post lift assembly
Mounting hardware for installation
12-piece truck adapter set (4 each of 2", 3", and 6" adapters)
Comprehensive installation manual
Installation Requirements:
Requires a minimum of 4" of concrete with 3000 psi rating. Ceiling height must be at least 12 feet to accommodate the single-piece column design. Oil not included – requires 3-5 gallons of AW32 or AW46 hydraulic oil.
